1029
Model Code Page
67. Powered front axle Carraro
1. 10. 1999
8450--8950 674 3
12. Remove the cassette sea and the o---ring (if fitted).
13. Unscrew the bevel pinio n shaft nut wit h spanner ETV
893 490. Prevent shaft from rotating in a suitable way.
14. Remove the nut and the lock washer on the shaft.
15. Knock out the shaft with a soft mallet. Take care of the
intermediate rings, compression bushing and the outer
bearing, which are released.
16. When necessary, drive out the shaft bearing outer races
in the differential bracket.
17. Remove the inner tapered roller bearing on the shaft
and remove the spacer ring under the bearing.
Note! The chamfered side of the spacer ring must be
turned to the bevel pinion side.
