495
Model Code Page
37. Autocontrol 5
1. 8. 2000
370 27
6250--8950
1. 6. 1999
B. Wiring diagrams AC5
(The diagrams also under code 310). Position of connec-
tors, see pages 310/6C och 6D.
A. Control unit A1 connector A1A1
F24: AC5 fuse in the fuse box
B6: Gearbox speed sensor
B7: PTO speed sensor
B11: Engine speed sensor
B12: Shuttle speed sensor
B13: Shuttle speed sensor
Position of connectors:
X13: Connector for transmission (37 pins) on the support
plate in the lever console.
X28: Connector for shuttle sensors (9 pins) in the lever con-
sole
X26: White connector (26 pins) in the rear face of the com-
bination instrument.
X1E: Connector (9 pins) for ACD power lift speed sensors
on the support plate in the lever console (also connector
X2E).
GR1: earth point in the rear part of the lever console
B. Control unit connector A1A2
P6: AC5 display unit
H10: PTO ind. light
Y11: Proportional valve, forward driving (F)
Y17: DPS proportional valve (C3)
Y12: Proportional valve, rearward driving (R)
Y2: PTO proportional valve (PTO)
Y4: DPS proportional valve (C1)
Y6: DPS proportional valve (C2)
Position of connectors:
X13: Connector for transmission (37 pins) on the support
plate in the lever console.
X27: Blue connector (26 pins) in the rear face of the combi-
nation instrument.
V1: diode box for solenoid valves Y1, Y2, Y3, Y4 and Y6 on
the support plate in the lever console.
V4: diode box for solenoid valves Y11, Y12 and Y17 on the
support plate in the lever console.
GR1: earth point in the rear part of the lever console
GR5:earthpoininthecabfrontwall
C. Control unit connector A1A3
B16: Clutch pedal position sensor
B14: Gearbox temperature sensor
B15: Gas pedal pisition sensor
B17: Outdoor temperature sensor
S23: DPS push buttons up/down
Position of connectors:
X13: Connector for transmission (37 pins) on the supportplate
in the lever console.
X19: Connector (37 pins) on the cab front wall on the RH side.
X1A: Connector (9 pins) for the engine sensors in the frontpart
of the engine compartment near the thermostat housing.
X23: Connector for DPS push buttons in the lower part of the
gear levers
X30: Connector (9 pins) for gear lever push buttons in the lo-
wer end of the levers.
GR1: earth point in the rear part of the lever console
D. Control unit connnectors A1A4 and A1A5
S45: HiShift push buttons in the gear lever knobs
S28: PTO switch at the PTO lever (540)
S29: PTO switch at the PTO lever (1000, 540E)
S47: Auto1/Auto2//Man switch for the DPS
S40: Reed relay, forward driving (F) (in the shuttle lever)
S41: Reed relay, rearward driving (R) (in the shuttle lever)
S51: DPS pre---programming button
S60: Seat safety switch (detection of driver)
H27: Back buzzer
K29: Relay for the back buzzer
Position of connectors:
X30: Connector (9 pins) for the gear lever push buttons in the
lower end of the levers.
X39: Connector (9 pins) for the shuttle lever at the steering
wheel under the dashboard.
X43: RS---232 connector on the lever console
GR1: earth point in the rear part of the lever console
GR5: earth point in the cab front wall
