Model Code Page
80. Cab and shields
1. 1. 1995
6000--8750 810 3
8. 11. 1990
Cab, general
3 4
A
B --- B
A
2
6
5
1
B
B
A --- A
1. Sound ---insulating shield.
2. Access hole (on the RH side mudguard). On the cabin floor there is also an access hole for fitting the clutch shaft coupling
sleeve.
3. Floor mat: rubber or polyurethane.
4. Insulating ma terial: foam rubber s=15mm (protected with polyurethane film).
5. The windscreen and door windows have been glued onto the cab frame in the beginning of the tractor production. Later the
glasses have been fastened with butyl rubber and plastic fasteners.
6. The hoses for the air conditioner (optional equipment) are located in the LH side front corner pillar (in the right side there are
the hoses for the cab heater).
