539
Model
No Page
FITTING INSTRUCTION 39.1
13.08.1993
1(4)6000---8750
REAR WINDOW WIPER AND WASHER
09.04.1998
Rear window wiper a nd washer 31611700.
Fitting wiper
motor:
--- Th er e a r e r e a d y --- m a de h o le s fo r t h e w i p e r m o t or
in the rear window (point A).
--- Remove the protective plugs, clean the window
and glue sticker 32534400 on the fastening point
on the inner side.
--- Fasten the wiper motor according to picture A.
--- Connect the motor to connector M5 which is
placed in the wire loom for the cab. The connector
can be found by opening a little the roof rear lin-
ings.
To tractor no 660794:
--- Remove the instrument panel cover by unscrewing
four cross-head screws and the starter switch nut.
Remove the cover and fit rocker switch 30943900.
--- Connect existing connector ” S32” (wire no 13,
120, 122 and 123 ) to the rocker switch and wires
no 26 and earth lead (white) to the indicating lamp
holder (picture C).
From tractor no 660795:
--- Remove the lever console longer switch panel. Cut
a hole on the panel (marked) for the switch frame
(picture D).
Fasten the switch S32 in the upper hole (cove rs on
the lower holes).
Seek connector ”S32” under the panel. If necess-
ary, remove the lever console side panel. Connect
connector to the switch (picture C) and fit the frame.
--- Switch on the wiper for a while and observe the ex-
treme stopping points of the wiper.
--- Fasten the wiper arm and the blade.
Fitting washer:
--- The washer reservoir bracket is attached under
the fixing screws of the LH side rear mudguard
(picture B).
--- Take supply voltage for the pump from existing
connector X18 in the wire loom 32275900.
--- Connect the wire loom and a water hose to the res-
ervoir pump and fit the reservoir.
--- D r i ll a h o l e ø 1 2 m m f o r t h e l e a d --- i n r ub b e r o f t h e
waterhose(seepictureB).
--- Pass the hose according to the picture, glue hose
fasteners (2 pcs) to the edge of the corner box and
fastenthehosetothebladewithfastener
30637400. Fit and direct the nozzle.
Function:
--- The wiper functions by pushing the rocker switch
to position I and washer by pushing continually the
switch.
