Note! IfHiShiftisretrofittedonanE---model,anew
parameter file must be copied into the AC IV unit. The
program diskette can be ordered from the Service
Department of Tractor Works.
438
Model Code Page
35. Autocontrol IV
1. 4. 1997
6100E
8100E-- 8750E
353 2
1. 1. 1994
Alternative parameter files
Tractors 6600E, 8100E, 8200E and 8400E have files which are selected according to the PTO type and display language:
Tractor Gearbox PTO Language Parameter file name
6600E ---8400E 30/40/50 km/h 540/1000 Finnish AC4011XX.NXS
Swedish AC4011XX.NXR
English AC4011XX.NXE
6600E ---8400E 30/40/50 km/h 540/540E (750) Finnish AC4012XX.EXS
Swedish AC4012XX.EXR
English AC4012XX.EXE
Parameter files on E---models which are equipped with HiShift
6600E ---8750E 30/40/50 km/h 540/1000 Finnish AC4013XX.NXS
Swedish AC4013XX.NXR
English AC4013XX.NXE
6600E ---8750E 30/40/50 km/h 540/540E (750) Finnish AC4014XX.EXS
Swedish AC4014XX.EXR
English AC4014XX.EXE
Copying parameter file into AC IV
In this instruction the Program is in the hard disk (C:). If it is in
the floppy disk drive, use a correct prompt (e.g. A:)
J Connect the PC with the cable to the socket X10C.
J Switch on the current to the tractor and to the PC.
JWhenpromptC:\> appears, type AC (ACC if colour
monitor) and press ENTER.
J A trouble shooting chart appears onto the PC display. In
the LH side lower corner of the chart there is the following
menu:
1PARAMETERS 5SENSOR LOG.
J Press F1 and the following text appears:
TRACTOR MODEL PARAMETERS
File name:____________________
J Type after colon a correct parameter file name.
JPressENTER
J Message PROGRAMMING AC ---IV appears onto the PC
display. Programming in action.
J When the programming is successfully completed, text
AC IV PROGRAMMED appears in the message window in
the RH side lower corner. During successful programming the
AC---IVdisplayisswitchedoffandon.
Note! Service Program error messages, see next page.
J To return to the disk operating system press function key
F10 (EXIT).
The Service Program chart (on PC display) has the following
information:
Parameter table no = parameter file order no
Date of production = manufacturing date of ECS
PROM Checksum = program version
EPLD Version = program version of logic circuit
If the central processing unit (ECS) or the parameter file is
changed, write on the ECS sticker no 32666800 tractor serial
number, date and parameter file name after text SW.NO. Fix
the sticker onto the ECS.
