Valtra 6550 - Checking ID Number of Program; Main Program Version Number; Parameter File ID Numbers

158
Model Code Page
37. Autocontrol 5.2 (K41107---)
1. 9. 2002
371 6B
6250--8950
1. 8. 2000
G. Checking ID number of program, AC
5.2:
PROGRAMS OF AC 5.2
Note! Programming instruction for AC5.2, see page
370---24.
In tractor production a program has input in the control unit
A1, which consists of a main program and a parameter file.
Both the main programs and the parameter files are of dif-
ferent types, and that is why they have ID numbers.
In the tractor display (in the test mode FII) can be seen the
program ID number, which shows the main program ver-
sion and the parameter file ID number. The two first digits
mean the parameter file ID number and the two last digits
the main program version number.
E.g. ID number 3181:
31 = parameter file number, 81 = main pro gram version
number.
Main program version number:
V ersio n Used in production
80
1)
K41107 --- K42439
81
2)
K42440 ---K45217
82 K45218 ---K50336
83 K50337 ---L27205
83 L27206 --- L36305 (parameter files changed)
84 L36306 --- L44126
85 Is no t fitted in produc tion.
86 L44127 ---
1) Version 80 has also be used in the pre---series, tractors
K25332, K25414, K26316, K26440, K34507, K35307.
2) Version 81 has been input in factory in some tractors
before no. K42440.
Parameter file ID numbers:
The parameter files have not been divided according to the
PTO type as in AC 5, but according to the tractor model.
The PTO ratios must be set in the setting mode FIII,see
page 370--- 19A.
For all main program versions have been done own para-
meter files. If the parameter files are developed, the ID
number increases one digit, e.g. 11 => 12. In this way dif-
ferent gener ations can be distinguished.
ID number Used in tractor models:
11, 16, 17 6250Hi --- 6850Hi, X100 --- X120
21, 26, 27 6250Hi --- 6850Hi HiT
rol
31, 36, 37 8050Hi --- 8150Hi
41, 46, 47 8350Hi
51, 56, 57 8450Hi --- 8950Hi
ID NUMBERS USED IN PRODUCTION, IN SP ARE
P ARTS AND IN SERVICE
Divided according to the main program version.
Beside the ID number there is information, which shows
whether the tractor has a correct program.
Note. If the ID number in the tractor display cannot be
found in this list, contact Valtra Tractor Service. In some
tractors there can be special programs.
Main program version 80.
Thesemustbereplacedwithmainprogramversion86.
ThesemustnomorebeusedinService
11 80
3)
6250Hi ---6850Hi, X100---X120
21 80
3)
6250Hi --- 6850Hi HiTrol
31 80
3)
8050Hi ---8150Hi
41 80
3)
8350Hi
51 80
3)
8450Hi ---8950Hi
Main program version 81
Thesemustbereplacedwithmainprogramversion86.
ThesemustnomorebeusedinService
11 81
3)
6250Hi ---6850Hi, X100---X120
21 81
3)
6250Hi --- 6850Hi HiTrol
31 81
3)
8050Hi ---8150Hi
41 81
3)
8350Hi
51 81
3)
8450Hi ---8950Hi
Main program version 82:
Thesemustbereplacedwithmainprogramversion86.
ThesemustnomorebeusedinService
11 82
3)
6250Hi ---6850Hi, X100---X120
21 82
3)
6250Hi --- 6850Hi HiTrol
31 82
3)
8050Hi ---8150Hi
41 82
3)
8350Hi
51 82
3)
8450Hi ---8950Hi
3) If the clutch pedal has malfunctions or the tractor has
malfunctions (e. g. fault codes P101...P109), the trans-
mission has jammed or if tractors transmission has not
disengaged complety with clutch pedal, with HiShift
button or with shuttle lever, then must a new program
be input (main program version 86 and parameter file).
Programming instructions on page 370---24B.Anew
program must be input in the control unit (main pro-
gram version 86). In version 86. the faults which are
found in versions 80---85, have been corrected and the
function has been improved.
