Valtra 6550 - Component List for Wiring Diagram

356
Model Code Page
34. Autocontrol ---III
6600E, 8100E 340 10
15. 6. 1992
1. 9. 1992
Component list for wiring diagram
(E--models). Diagram no. 325 499 00 32B.
S y m --- C o d e
bol Component no
(A2) Radio 2
A3 Distribution box
(A4) Velocity meter
(A5) Seat with air springs 67
(A7) Electric air filter 68
(A8) Buzzer control
B 1 Sender unit, engine temperature 13
B 2 Sender unit, fuel gauge 16
E1 Headlights,right 24
E2 Headlights,left 23
E 3 Front direction indicator, right 28
E 4 Front direction indicator, left 26
E 5 Rear light, right 31
E 6 Rear light, left 30
E7 Cabinlight 43
E 9 Rear working light, right outer 38
E10 Rear working light, right inner 37
E11 Rear working light, left outer 39
E12 Rear working light, left inner 38
E13 Front working light, right 41
E14 Front working light, left 41
E15 Instrument light 14,16
E16 Roof console light 51
(E17) Seat heating 67
(E18) Foot step light 42
(E20) Parking light, right Norway 27
(E21) Parking light, left Norway 27
(E22) Number plate light
F 1 15 A Hazard warning flasher, reserve 29
F2 5A Radio(clock), 2
F3 10A Mainbeams,---ind.light 23
F 4 10 A Dipped beams 23
F 5 5 A Parking light, left 26
F 6 5 A Parking light, right 28
F 7 10 A Front working lights 40
F 8 20 A Light switch 27
F 9 15 A Trailer socket 31
F10 15 A Starter switch, thermostart 4
F11 5 A Autocontrol (+30) 69
F12 10 A Rot. warning light, cabin and door light 44
F13 10 A Brake lights 54
F14 10 A Reserve 66
F15 20 A Fan III---speed 49
F16 10 A Rear working lights, inner 38
F17 10 A Direction indicators 29
F18 5 A Instruments, warning lights, Autocontr. 14
F19 10 A Combination lever, wiper return 20
F20 10 A Rear window wiper/washer 45
F21 15 A Fan I, II, Air conditioner, Floor fan 48
F22 10 A Solenoid valves, ECS 57
F23 10 A Rear working lights, outer 38
F24 10 A ECS 85
F25 10 A Seat with air springs, seat heating 67
F26 10 A Reserve/electric air filter 68
F27 10 A Reserve 68
F28 10 A Reserve (telephone) 66
F29 10 A Cigarette lighter, Power socket 35
F30 10 A Reserve 56
S y m --- C o d e
bol Component no
G 1 Battery 1
G2 Alternator 4
H 1 Ind. light, direction indicator III 34
H 2 Ind. light, direction indicator II 33
H 3 Ind. light, direction indicator I 32
H 4 Warning light, engine air filter 7
H 5 Warning light, engine oil pressure 8
H 6 Warning light, STOP, engine temp. 13
H 7 Warning light, gearbox oil pressure 9
(H8) Gearbox oil filter
H9 Ind.light,4WD 58
H10 Ind. light, PTO 540 61
H11 Ind. light, parking brake 11
H12 Ind. light, thermostart 5
H14 Ind. light, main beams 22
H15 Warning light, low fuel level 12
H16 Ind. light, charging 6
H18 Warning light, gearbox oil temperature 12
H20 Warning light, differential lock 57
H21 Ind. light, PTO 1000 61
H22 Reserve/Ind. light, quick---shift gear (ECS)
H23 Horn 18
(H24) Rotating warning light 44
K1 Relay, front working lights 40
K 2 Relay, rear working lights 38
K3 Relay, thermostart 55
K 4 Starter switch relay 7
K 5 Starter switch relay 9
K 6 Relay, fan III speed 49
K7 Brakelights(ECS) 56
K9 Relay,intervalwiper 20
K10 Direction indicator relay 31 ---32
K14 Starter motor relay 4
M 1 Starter motor 3
M2 Fan 48
M 3 Windscreen wiper 21
M 4 Windscreen washer 19
(M 5) Rear window wiper 46
(M 6) Rear window washer 45
M 7 Floor fan 50
P 1 Engine coolant thermometer 14
P2 Fuelgauge 16
P 3 Revolution counter 16
P 4 Hour recorder/working height 17
Q 1 Starter switch 4
(Q 2) Main circuit breaker 2
R1 Thermostart 6
(R 4) Cigarette lighter 35
S 1 Switch, headlights 25 ---26
S2 Switch,rearworkinglights 37
S3 Switch,fan 48
S 4 Combination control 19
S 5 Switch, front working lights 40
(S6) Switch,rot.warninglight 44
S 7 Switch, hazard warning flashers 30
(S 8) Switch, air conditioner 47
