357
Model Code Page
34. Autocontrol ---III
6600E, 8100E 340 11
15. 6. 1992
1. 9. 1992
S y m --- C o d e
bol Component no
S 9 Safety circuit breaker 4
S10 Brake light contact, right 54
S11 Fuel gauge sender unit 16
S12 Pressure drop indicator, air filter 7
S13 Engine oil pressure sender unit 8
S15 Sender unit to hand brake ind. light 11
S16 Gearbox temperature sender unit 12
S17 Gearbox oil pressure sender unit 9
S18 Engine temperature sender unit (STOP) 13
(S19) Air cond. compressor pressure switch 47
S20 Brake light contact, left 54
S22 Switch, differential lock 89
S23 Switch, quick---shift gear (engaging) 95
S24 Switch, quick---shift gear (disengaging) 58
S25 Switch, power take---off 63
S28 Switch, PTO 540 62
S29 Switch, PTO 1000 65
S30 Switch, 4WD 88
S31 Switch, floor fan 50
(S32) Switch,rearwindowwasherandwiper 45
(S52) Switch, floor 42
V 1...4 Diode
X 1 Connector, 9 pins, distribution box
X 2 Connector, 9 pins, distribution box
X 3 Connector, 9 pins, distribution box
X 4 Connector, 9 pins, distribution box
X 5 Connector, 9 pins, distribution box
X 6 Connector, 9 pins, distribution box
X 7 Connector, 9 pins, distribution box
(X 8) Connector, 2 pins, power socket 36
X 9 Connector, 9 pins, combination control
X10 Connector, 9 pins, combination control
X11 Connector, 9 pins, upwards
X12 Connector, 9 pins, rearwards, right
X13 Connector, 4 pins, solenoid valves
X14 Connector,9pins,rearwards,left
X15 Connector, 3 pins, air cond., diodes
X16 Connector, 3 pin., cigarette lighter, current socket
X17 Trailer socket 7 pins 30
X18 Connector, 2 pins, rear window washer
X19 Connector, 37 ---pins. ECS , front wall 10
X20 Connector, 9 pins, front direction ind.
X21 Connector, 3---pins, buzzer
X22 Connector, 1 pin, rot. warning light
X24 Connector, 9 pins., upwards
X26 Connector, 26 pins, instr. left white
X27 Connector, 26 pins, instr. right blue
X28 Connector, 6 pins, diodes
X49 Connector, 2 pins, seat
Y 1 Solenoid valve, diff. lock 56
Y 2 Solenoid valve, PTO 63
Y 3 Solenoid valve, 4WD 60
(Y 4) Solenoid valve, quick---shift gear 65
(Y 5) Solenoid valve, compressor 47
/1 Earth lead, rear lights
/2 Earth lead, roof
/4 Earth lead, Autocontrol
/5 Earth lead, cable harness instr. panel
/7 Earth lead, battery
/8 Earth lead, headlights
/9 Earth lead, cab
Optional equipment listed in brackets.
ECS
S y m --- C o d e
bol Component no
A1C Central processing unit (ECS), red 80
A2C Central processing unit (ECS) 91
B1C Speed sensor, rear wheel 78
B2C Speed sensor, gearbox 78
B3C Speed sensor, PTO 79
B4C Speed sensor, engine 79
B5C Speed sensor, front axle 78
B7C Radar 77
B8C Potentiometer, fuel injection pump 87
B9C Temperature sensor, thermostart 93
B10C Outdoor temperature sensor 92
H1C Buzzer 94
H2C Led, slip control
S1C A/M ---switch, diff. lock 88
S 2 C A / M --- s w i t c h , q u i c k --- s h i f t g e a r 9 1
S 3 C A / M --- s w i t c h , 4 W D 8 8
S4C Switch, steering angle 90
S5C Switch, slip control
X1C Connector, 9 pins, front (yellow)
X2C Connector, 15 pins, speed sensors
X3C Connector, 9 pins, rear sockets (black)
X4C Connector, 3 pins, rear sockets (black)
X5C Connector, 9 pins, switches on lever knobs
X6C Connector, 12 pins., Autocontrol switch panel 74
X7C Connector, 3 pins, Autocontrol cable harness
X8C Connector, 9 pins, outputs (red)
X9C Connector, 1 pin, PTO manual control
X10C Connector, 8 pins, RS232/RS485
X11C Connector, 9 pins, display unit 77
X12C ECS--- socket 13 pins
X13C PTO emergency switch, socket, 2 pins. 62
