1095
Model Code Page
70. Frame and wheels
15. 5. 1996
6000--8750 720 1
1. 1. 1994
Tyres and track widths
Tyres (alternative tyre equipment)
When changing tyres, make sure that the ratio between the front and rear axles becomes correct, see also page 640/2. Allways
when changing tyres, check that the front wheels do not touch the frame at max steering angle. If necessary, limit the steering
angle with limiter screws.
Etu Taka 6000, 6100
4)
6300, 6400, 8000
4)
6600, 8100, 8200, 8400
11.00---16/8 13.6R38/8 X X
11.00---16/8 14.9R38/8 X X
11.00---16/8 16.9R34/8 X X
11.00---16/8 16.9R38/8 X X
12.4R24/8 13.6R38/8 X X
13.6R24/8 14.9R38/8 X X
13.6R24/8 16.9R34/8 X X
14.9---24/8 16.9---34/8 X X
14.9---24/8 18.4---34/8 X X X
14.9R24/8 18.4R34/8 X X X
1)
14.9R28/8 18.4R38/8 X X
14.9---28/8 18.4---38/8 X
16.9R28/8 20.8R38/8 X
480/65R24 600/65R34 X X
480/65R28 600/65R38 X X
19.5R24 620/75R30 X X
540/65R28 650/65R38 X
14.9---24/14 IND 18.4---34/14 IND X X X
14.9---24/14 FOR 18.4---34/14 FOR X X X
14.9---28/14 FOR 18.4---38/14 FOR X X
14.9R28/8 18.4R38/8 X X
16.9R28/8 20.8R38/8 X
3)
13.6---24/12 IND 16.9---34/14 IND X X
16.9R28 20.8R38 X
16.9---24/14 IND 18.4---38/14 IND X
14.9R28 18.4R38 X
2)
14.9---28/14 FOR 18.4---34/14 FOR X
14.9---24/14 IND 18.4---34/14 IND X
1
) Depands on tyre type and manufacturer.
2
) Industrial front axle.
3
) Fixed discs.
4
) on 6000---6400, 8000 with front/rear axle ratio
1,334 (without quick---shift gear, pinion shaft/crown wheel 9/38) and with ratio 1,332 (with Delta P o wer Shift, pinion shaft/crown
wheel 8/42)
Wheem nuts, tightening torques
--- W h ee l n u t s, fro n t 55 0 N m..................
rear 550 Nm...................
--- R i m --- w h ee l di sc ( f r on t a n d rea r), 8. 8 2 4 0 N m...
---Rim---wheel disc (front and rear), 10.9 310 Nm..
Note! Retightening of the wheel nuts sho uld be done according to the Service Program.
