Model
Code Page
1(2)79.5
EXTRA FUEL TANK, FITTING INSTRUCTION
11.04.2000
06.04.2000
6250Hi--8950Hi
6000---8750
Extra fuel tank 6000---8750 33627000.........
Note! Fuel tank draining plug thread should be
M30x1,5 (from tractor ser. no. 664868 --->).
The extra fuel tank capa city is 85 litres, which can
be an addition to the fuel in the standard tank.
When filling the tank, observe that in the end the fill-
ing happens slow er due to resistance of fuel flow.
--- Fitting extra tank:
--- Drain the fuel tank. Remove the footstep iron.
H i Te c h --- m o d e l s : remove the w ires which go to the
endpieceoftheparkingbrakecylinder(S52).
--- Tractors to tractor no. ---J10111: Assemble the fuel
filling hole extension piece according to the pic -
ture. Check that the o---ring 17 remains in its
groove when You tighten the sleeve 5 .Tightenthe
sleeve as hard as possible using e.g. an oil filter
spanner.
--- Fasten the damper sticker 10 onto the extra tank
and also bands 11 (7 off) onto the frame 12.
--- Unscrew the nut of the lower stud bolt (M16) and
the upper hexagonal socket screw M12 on the LH
side in the bolted joint between gearbox---fueltank.
Fasten the support 18 with nut and screw.
Place the frame 12 temporarily into place. Estimate
the position of the cut---off point of the footstep RH
side support iron. Mark places for the fixing holes
(ø18 mm) on the footstep iron and drill the holes.
H i Te c h --- m o d e l s : leave the footstep support
(33598300) away.
--- If the tractor has an air conditioner and its hoses
have been drawn behind the cab front attachment,
the hoses should be moved to the front side of the
attachment. In this case, unscrew the cab front
attachingbolts and slackenthe cab rear bolts. Also
the PTO control cable should be detached. Raise
the cab about 50 mm and move the hoses to the
front side of t he attachment. (Note! Remove out
from way the attaching screws of the engine heater
socket). Also detach the drier and push excess
hose length into the engine compartment.
--- Conn e c t t he h o s e 4 to the extra fuel tank and
fastenframeandthetank.Thetankfrontendis
attached to the rear face of the cab attachment and
the rear end is attached with the support 18.
NOTE! Guide e.g. with a flat iron the edge seal
of
the intermediate frame protective shield so that
it
stays betw een the tank and the
intermediate
frame.
--- Ch an g e t h e l o w e r s hie ld 40 ontheleftsideofthe
cab.
