1114
Model
Code Page
2(3)79
WAT ER RESERV OIR, FITTING INSTRUCTION
26.09.1994 6000---8400
04.06.1993
--- Open the lever console side panel and detach the
longer upper panel. Cut a hole for the switch frame
28.Fastentheparts28, 29 and the switch 27 into
place.
Draw the wiring loom connector S34 + ind. lamp
wire to the sw itch. Fasten the upper panel. Con-
nect the earh connector under the earth screw in
the lever console bottom. Pass the rest of the wires
out of the console through its rear corner.
--- Draw wire nr 166 (green) together with other wires
to the fuse box. Disconnect connector X6 and con-
nect the wire to the connector pole 6. Tape the wire
to the side of the other wire looms. Change fuse
F14(10A) intoafuseof15A.
--- Draw the wire no 167 (red) to the cab LH side rear
corner and further through the lead---in point to the
pump. Fit the connector 11A on the wire. Connect
the earth connector 11C to the pump black wire
and connector 11B to the pump red wire.
Fitthe pump (earth cable shoe under one pump fix-
ing screw). Connect the pump suction and press-
sure hoses.
--- Fill the tank (at least up to the pump level). Check
the function of the pump and check for leaks.
1 32837200 Vesisäiliö Vattentank Water tank Waßertank
1 1 32819400 .Säiliö Behållare Container Behälter
1A 1 KH3610 ..Tiiviste Tätning Gasket Dichtung
1B 1 GR0225 ..Tulppa Plugg Plug Stopfen
2 2 32021500 .Tiiviste Tätning Gasket Dichtung
3 7 32697500 .Tiiviste Tätning Gasket Dichtung
4 1 32816010 .Kehys Ram Frame Rahmen
5 1 32816200 .Laatta Platta Plate Platte
6 1 JB8907 .Mutteri Mutter Nut Mutter
7 4 HA9242 .Ruuvi Skruv Screw Schraube
8 6 JB8906 .Mutteri Mutter Nut Mutter
9 1 32837600 .Putki Rör Pipe Rohr
10 2 GP3927 .Letkunkiristin Slangklämma Hose clip Schlauchbinder
11 1 32837400 .Pumppu Pump Pump Pumpe
11A 1 SA1527 Liitinkotelo Skarvhus Connector housing Klemmschutz
11B 1 SA1687 Liitin Anslutning Connection Klemme
11C 1 SA1763 Maadoituskenkä Jordanslutning Earth connector Klemme
12 1 GS9112 .Liitin Nippel Union Verbindung
13 1 GP3916 .Letkunkiristin Slangklämma Hose clip Schlauchbinder
14 1 .Letku Slang Hose Schlauch
15 4 JD0405 .Aluslaatta Bricka Washer Scheibe
16 4 HA6306 .Ruuvi Skruv Screw Schraube
17 2 GP3941 .Letkunkiristin Slangklämma Hose clip Schlauchbinder
18 1 32837500 .Letku Slang Hose Schlauch
19 2 HA6343 .Ruuvi Skruv Screw Schraube
20 1 32836800 .Täyttöputki P åfyllningsrör Filling pipe Einfüllungsrohr
21 1 32861800 .Korkki Lock Cap Deckel
22 1 32841410 .Kiinnitin Fästdon Fastener Halter
23 2 HA6324 .Ruuvi Skruv Screw Schraube
24 2 625510 .Aluslaatta Bricka Washer Scheibe
25 2 JB8904 .Mutteri Mutter Nut Mutter
26 32837810 .Letkukela Slangtrum Hose dram Schlauch rulle
27 1 30944200 .Keinukytkin Vippströmbrytare Switch Schaukelschalter
1 30944600 .Lampunpidin Lampfattning Bulb socket Lampenfuß
1 32862300 .Linssi Lins Lens Linse
