AIR CONDITIONING, FIT TING INSTRUCTION
(P T 94 --- cabin)
30.07.1999
3 (28)
28.06.1999
6000---8750
6250Hi---8950Hi
FITTING:
Condenser (picture 1a,b).
--- Remove both engine side plates. Lift up t he
openable front plastic covering. Remove protec-
tive shield (32839500) in front of the cooling radi-
ator. Clean the radiator fins with compressed air.
--- Fit the condenser above the oil cooler (picture
2).
--- Fit the condenser u pper end securing parts in
position, picture 1a,b,c (numbers in brackets
intend parts which are a lready fitted on the trac-
tor).
--- NOTE! The condenser is a very sensitive com-
ponent and must be handled with care. Support
the pipes of the condenser when tightening the
hoses (tightening torque, see picture), so that
the condenser is not bent.
-- 6000-- 6600 tractors: Part 16 (nut M8) is
intended to be an intermediate part
Cut a piece of edge band 89 and fit it onto the
net hole edge and other piece to the lower edge.
--- 6250Hi--6850Hi tractors: Fit the condenser
with parts 87H---99H.
-- 6900-- 8400 tractors: Place t he edge band 89
round the protective net hole.
--- 8050--8750, 8050Hi--8950Hi tracto rs:Fitthe
condenser with parts 87S---99S.
--- For easier cleaning, leave enough free length for
hoses 4 and 120. Fit the a ngle unions first for
eliminating possible winding faults (after fitting
the compressor and drier).
Drier (picture 2).
--- Fit the drier according to the figure.
--- Connect pressure switch 33 + O --- ri n g 71 to the
hose 121 (6000---6600: to the drier 32).
--- Cut an opening (like a hole on the plate)
through the covering for the hoses.
--- CONNECT THE HOSES TO THE DRIER JUST
WHEN OTHER FITTINGS ARE DONE. (the drier
becomes easily saturated by humidity in air).
--- Fit the wiring loom 34. Connect wires no 33 and
93 to the pressure switch poles 1 and 2. Other
end of t he wire no 33 is connected to the com-
pressor a nd other end of the wire 93 to the wire
which has the same number in the engine w ire
loom. The wires are situated under the battery
shelf on the RH side of the tractor.
