1261
Model
Code Page
1(2)
6600---8750
99
EXTRA OIL RESERVOIR, fitting instruction
22.08.1996
(not 8000)
Extra oil reservo ir 33141900...............
The oil reservoir volume is 19 litres, 15 l of which can
be used e.g. for the auxiliary hydraulics.
The reservoir is fitted under the LH side final drive.
The ground clearance does not become smaller.
The s teering system return oil pipe is connected to
the reservoir. Thus the cooling effect increases. Also
the oil in the reservoir is kept warmer in the cold sea-
sons. The gearbox oil draining is done through the
reservoir draining plug 2.
FITTING:
--- Support the tractor and remove the LH side rear
wheel. Unscrew the gearbox oil draining plug and
drain the oil.
--- Disconnect the steering return oil connector Y on
the gearbox and connect it to the reservoir 1.In
place of the connector are fitted parts 14 and 15.
Fasten connecting pipe parts 3, 8 to the gearbox
and parts 4, 3, 2 ,9 to the reservoir.
--- Fit the extra reservoir 1 (it is fastened with two
br a k e h ou s in g --- t o --- fi n a l d r i v e b olt s, s e e p ic t ur e B ) .
Do not yet tighten the bolts!
--- Fit t he steering system return oil pipe. Assemble
the connecting pipe parts 5 --- 7 and tighten them.
After that is tightened the reservoir attaching bolts
(tightening torque = 80 Nm).
--- Disconnect the lifting cylinder breather pipe end
on the brake housing. Attach the parts 12 --- 13 to
the hose 10. Fix connector 12 in place of the
detached hose. Fit hose 11. Connect the breather
pipe end to t he connector 13.
Note! Do not tighten the connectorstoo hard (seal -
ing surfaces can damage)
--- If the tractor has the trailer brake cylinder, the
hoses are connected as shown in picture C.
--- Fit the wheel. Fill the gearbox housing with oil. Add
19 litres oil (volume of the extra reservoir. NOTE!
the extra reservoir makes the filling slower.
1 33141900 Öljysäiliö Oljebehållare Oil tank Ölbehälter
1 1 33080400 .Säiliö Behållare Container Behälter
2 1 GR0225 .Tulppa Plugg Plug Stopfen
3 2 KH3610 .Tiiviste Tätning Gasket Dichtung
4 1 GS9382 .Liitin Nippel Union V erbindung
5 1 33142200 .Putki Rör Pipe Rohr
6 1 33185900 .Liitin Nippel Union Verbindung
7 1 GS9332 .Liitin Nippel Union V erbindung
8 1 33080500 .Liitin Nippel Union Verbindung
9 2 GS9270 .Liitin Nippel Union V erbindung
10 1 33142000 .Letku Slang Hose Schlauch
11 1 33142100 .Letku Slang Hose Schlauch
12 1 GS9268 .Liitin Nippel Union Verbindung
13 1 GS9276 .Liitin Nippel Union Verbindung
14 1 GR0284 .Tulppa Plugg Plug Stopfen
15 2 KH4946 .Tiiviste Tätning Gasket Dichtung
