166
Model Code Page
31. Tractor electrical system
6000--8400 310 16
15. 4. 1995
1. 1. 1994
Wiring diagram from tractor serial
number 662343 up to no 668102.
(E-- models, see section 35). Diagram no 318 716 30B.
See diagrams on pages 310/18 ---20. This diagram incl. also
Autocontrol II system.
S y m --- C o d e
bol Component no
(A 2) Radio 2
A3 Electriccentre
(A 4) Speedometer + clock 93
(A 5) Air suspension seat 94
(A 6) Agrodata 95
(A 7) Electric air filter 96
(A 9) Ind. lights, Delta Powershift 71
(A 10) Control unit, Delta Power shift 70
(A 11) Telephone 99
B 1 Sensor, engine temperature 16
B 2 Sensor, fuel gauge 17
(B 8) Sensor, wheel speed 93
E1 Headlights,right 26
E2 Headlights,left 25
E 3 Front direction indicator, right 31
E 4 Front direction indicator, left 28
E 5 Rear light, right 33
E 6 Rear light, left 32
E7 Cabinlight 46
E 9 Rear working light, right outer 42
E10 Rear working right, right inner 42
E11 Rear working light, left outer 41
E12 Rear working light, left inner 41
E13 Front working light, right 44
E14 Front working light, left 44
E15 Instrument lights 17
E16 Roof console lights 21
(E17) Seat heater 94
(E18) Footstep light 45
(E19) Rear fog light 35
(E20) Parking light, right, Norway 29
(E21) Parking light, left, Norway 30
(E22) Register plate light 32
(E23) Upper head light, right 24
(E24) Upper head light, left 23
(E25) Parking light, upper, right 22
(E26) Parking light, upper, left 22
F 1 15 A Hazard blinkers, reserve 31
F 2 5 A Radio, clock 2
F 3 10 A High beam, indicator light 25
F 4 10 A Low beam 25
F 5 5 A Parking lights, left 28
F 6 5 A Parking lights, right 30
F 7 10 A Front working lights 44
F 8 20 A Light switch 28
f 9 15 A Trailer socket, rear fog light 35
F10 15 A Starter switch, thermostart 4
F11 5 A Autocontrol (+Bat), buzzer 83
F12 10 A Rot. warning light, cabin and footstep light 47
F13 10 A Reserve 100
F14 15 A Water pump 97
F15 20 A Fan III --- speed 56
F16 10 A Rear working lights, inner 42
F17 10 A Direction indicators, agrodata 32
F18 5 A Instruments, warning lights, Autocontrol 17
F19 10 A Combination switch, wiper return 51
F20 10 A Rear w. wiper/washer 48
F21 15 A Fan I, II, air conditioner., floor fan 55
F22 10 A 4WD, PTO, Delta Power Shift 65
F23 10 A Rear working lights, outer 41
F24 10 A Speedometer 93
F25 10 A Air suspension seat/seat heating
reverse drive control lock 94
F26 10 A Electric air filter 96
S y m --- C o d e
bol Component no
F27 10 A Brake lights, differential lock 62
F28 10 A Telephone 99
F29 10 A Cigarette lighter, power socket 91
F30 10 A Rear fog lights 102
G 1 Battery 1
G2 Alternator 4
H 1 Pilot light, direction indicator III 34
H 2 Pilot light, direction indicator II 34
H 3 Pilot light, direction indicator I 34
H 4 Warning light, air filter 7
H 5 Warning light, engine oil pressure 8
H 6 Warning light, stop, engine temp. 15
H 7 Warning light, gearbox oil press. 9
(H 8) Pilot light, oil filter, gearbox 10
H 9 Pilot light, 4WD 65
H10 Pilot light PTO 67
H11 Pilot light, parking brake 12
H12 Pilot light, Thermostart 6
H14 Pilot light, main beams 27
H15 Warning light, low fuel level 14
H16 Warning light, charging 6
H18 Warning light, gearb. oil temp. 13
H20 Pilot light, diff. lock 62
H22 Reserve
H23 Horn 50
(H24) Rotating roof light 47
K 1 Relay, front working lights 43
K 2 Relay , rear working lights 41
K3 Rearfoglights 35
K 4 Starter switch relay 7
K 5 Starter switch relay 9
K 6 Relay, fan III 56
K 7 Relay, four wheel braking 65
K9 Relay,intervalwiper 53
K10 Direction indicator relay 34
K11 Relay,brakelights,diff.lock 63
K12 Relay, differential lock 61
K13 Relay, differential lock 63
K14 Starter motor relay 4
K15 Relay, 4WD 65
K16 Relay, PTO emergency stop 68
M 1 Starter motor 3
M2 Fan 55
M 3 Windscreen wiper 53
M 4 Windscreen washer 51
(M 5) Rear window wiper 49
(M 6) Rear window washer 48
(M 7) Floor fan 57
(M 8) Water pump 97
P 1 Engine coolant thermometer 16
P2 Fuelgauge 17
P 3 Revolution counter 18
P 4 Hour recorder/work. height 19
Q 1 Starter switch 4
(Q 2) Main switch 3
R1 Thermostart 5
(R 4) Cigarette lighter 91
S 1 Switch, head lights 28
S2 Switch,rearworkinglights 41
S3 Switch, fan 55
