74
1. 9. 2002
310 102
6200--8550
Model Code Page
31. Tractor electrical system
S y m --- C o d e
bol Component no
K1 Relay, front working lights 43
K2 Relay, rear working lights 41
(K3) Relay, fog light, rear 35
K4 Auxiliary relay, st arter switch 7
K5 Auxiliary relay, st arter switch 9
K6 Relay, fan III 56
K7 Control relay, 4---wheel brake 65
K9 Relay, interval wiper 53
K10 Direction indicator relay 34
K11 Relay, brake lights/differential lock 64
K13 Control relay, differential lock 65
K14 Starter motor relay 4
K15 Control relay, 4--- wheel drive 69
K16 Relay, PTO ---emergency stop 68
(K18) Relay, control stop 8
(K24) Control relay, HiShift 115
K26 Control relay, speed limit, HiShift
K27 Control relay, 4WD on/off 68
(K51) Warning light, main switch 166
K56 Time---delay relay, cab light 97
M1 Starter motor 3, 167
M2 Fan 55
M3 Windscreen wiper 53
M4 Windscreen washer 51
(M5) Rear window wiper 48
(M6) Rear window washer 47
M7 Floor fan 57
(M8) Water pump 95
(M9) Roof window wiper 49
P1 Engine temperature meter 16
P2 Fuel gauge 17
P3 Tachometer 18
P4 Running hour meter 19
P5 Clock, PTO---speed, AC, trip, oil temperature,
speed (Agroline instrumentation) 101
Q1 Heat/starter switch 4
(Q2) Main switch 3, (167)
R1 Thermostart 5
R4 Cigarette lighter 91
R7 Potentiometer, front PTO, starting speed 161
S y m --- C o d e
bol Component no
S1 Switch, head lights 28
S2 Switch, rear working lights 41
S3 Switch, fan 55
S4 Combined switch 25, 34, 52
S5 Switch, front working lights 43
(S6) Switch,rot.warninglight 99
S7 Switch, hazard warning flashers 32
(S8) Switch, air conditioner 54
S9 Starter safety switch 4
S10 Switch, braking lights, right 72
S11 Fuel gauge sender unit 17
S12 Pressure drop indicator, air filter 7
S13 Engine oil press. sender unit 8, 118
S15 Sender unit to parking brake ind. light 12
(S15) Reed relay, parking brake (P) 149
S16 Gearbox temperature sender unit 13
S17 Gearbox oil pressure sender unit 9, 119
S18 Engine temperature sender unit (stop) 16
(S19) Switch, compressor pressure 54
S20 Switch braking lights, left 73
S22 Switch, differential lock 62
(S23) Switch, DPS, selector 70, 71
S24 Switch, DPS, release 69
S25 S witch, PTO 75
(S26) Switch, fog light rear 35
(S27) Switch, reverse buzzer 45
S28 Switch, PTO 540 68
S29 Switch, PTO 1000/540E 67
S30 S witch, 4WD 68
S31 Switch, floor fan 57
(S32) Switch, rear window wiper and washer 47
(S33) Change over switch, head lights up 23
(S34) Switch, water pump 96
(S35) Switch, rear steering prevention 94
(S36) Switch, control stop 4
(S38) Switch, front ---PTO 162
(S42) Door switch, cab light, RH 97
(S43) Door switch, cab light, LH 98
(S44) Indicator light switch, filter 180 bar 11
(S45) Switch, HiShift 115, 142
(S45.1) Extra switch, HiShift 115
(S49) Change over switch, rpm/flow sensor
(S50) Change over switch, speed sensor, tractor/
implement
(S53) Indicator light switch, filter, return 10
(S54) Indicator light switch, filter, 18 bar 11
(S59) Switch, roof window washer 49
S68 Switch, main switch control 168
S80 Switch, instrumentation, display size setting 103
(S83)Switch, trailer hitch light 101
(S84)Switch, extra front working lights 46
V1 Diodes Y1, Y2, Y3, Y4, Y6
V 2 D i o d e s , A C --- 2
V3 Diodes Y1, Y2, Y3, Y4, Y6 65
(V5) Diodes, HiShift 115
