289
Model Code Page
32. Autocontrol power lift
15. 5. 1996
6000--8400 320 3D
AC power lift, F17107---.
S y m --- Code
bol Component no
A1E Autocontrol electronic unit 82
A2E Autocontrol, switch panel 83
A3E Compensator 82
B1E Position sensor 81
B2E Draft sensor, right 81
B3E Draft sensor, left 81
E1E Illumination, switch panel 83
E2E Illumination, position control knob 83
R1E Potentiometer, position control 83
S1E Push button, mudguard, lifting, right 82
S2E Push button, mudguard, lowering, right 82
S3E Push button, mudguard, lifting, left 82
S4E Push button, mudguard, lowering, left 82
S5E Rocker switch, cabin, lifting/lowering 82
S7E Switch, lowering speed 83
S8E Switch, transport height 83
S9E Switch, mixing/sensitivity 83
S10E Autocontrol rocker switch, lift/stop/lower 83
S11E Rocker switch, forced lowering 83
X2E Connector, 9 pins, supply, push buttons
Y1E Solenoid valve, lowering 82
Y2E Solenoid valve, lifting 82
Wire colours
Ru = brown
Pu = red
Ke = yellow
Si = blue
Mu = black
Vi = green
Va = white
Li = lilac
