35. Autocontrol IV
1. 4. 1997
6600E-- 8750E
350 19
15. 5. 1996
Wiring diagram, E---models,
F17107--- F50111
Diagrams on pages 350/23 ---25. Incl. new cab wire loom
and a new relay control for PTO.
S y m --- C o d e
bol Component no
(A2) Radio 2
A3 Electric centre
(A5) Air suspension seat 93
(A7) Electric air filter 97
A10 Control unit, Delta Power Shift 101
(A11) Telephone 97
(A13) Control unit, Sigma
(A14) Tach ogra ph 1
B 1 Sensor, engine temperature 16
B 2 Sensor, fuel gauge 17
(B4) Sensor,Sigma,crankshaft
(B5) Sensor,Sigma,PTO
(B9) Sensor, tachograph 1
E1 Headlights,right 26
E2 Headlights,left 25
E 3 Front indicator, R.H 31
E 4 Front indicator, L.H 28
E 5 Rear light, right 33
E 6 Rear light, left 32
E7 Cabinlight 46
E 9 Rear working light, R, outer 42
E10 Rear working right, R, inner 42
E11 Rear working light, L, outer 41
E12 Rear working light, L, inner 41
E13 Front working light, right 44
E14 Front working light, left 44
E15 instrument lights 17
E16 Roof console lights 21
(E17) Seat heater 93
(E19) Fog light, rear 35
(E20) Parking light, right, Norway 29
(E21) Parking light, left, Norway 30
(E22) Registration plate light 32
(E23) Upper head light, right 24
(E24) Upper head light, left 23
(E25) Parking light, upper, right 22
(E26) Parking light, upper, left 22
F 1 15 A Hazard light, reserve 31
F 2 5 A Radio, clock, tachograph 2
F3 15 A High beams, indicator light 25
F4 15 A Low beams 25
F 5 5 A Parking lights, left 28
F 6 5 A Parking lights, right 30
F 7 10 A Front working lights 44
F 8 20 A Light switch 28
F 9 15 A Trailer socket/rear fog light 35
F10 15 A Heat/starter switch,
thermostart 4
F11 5 A Autocontrol (+bat), buzzer 82,103
F12 10 A Rot. warning light, cabin light 47
F13 10 A Reserve 92
F14 15 A Water pump 94,96
F15 20 A Fan III --- speed 56
F16 10 A Rear working lights, inner 42
F17 10 A Direction indicators 32
F18 5 A Instruments, warning lights
Autocontrol 17
F19 10 A Combination switch, wiper return 51
F20 10 A Rear window wiper/ washer 48
F21 15 A Fan I,II, air conditioner, floor fan 55
F22 10 A Delta Power Shift 100
F23 10 A Rear w. lights, outer 41
F24 10 A AC---4 control unit 68
F25 15A Seat with air suspension, seat
heating, rear steering prevention 93
F26 10 A Back buzzer, trailer brakes,
Sigma
F27 10 A Braking lights 61
F28 10 A Reserve (Telephone) 97
F29 10 A Cigarette lighter, power socket 91
F30 10 A ACIV sensors, PTO 64
(F31) 15 A Electric air filter 97
G 1 Battery 1
G2 Alternator 4
H 1 Indicator light, direction indicator III 34
H 2 Indicator light, direction indicator II 34
H 3 Indicator light, direction indicator I 34
H 4 Indicator light, air filter 7
H 5 Indicator light, engine oil pressure 8
H 6 Warning light, stop, engine temp. 15
H 7 Indicator light, gearbox oil pressure 9
(H8) Indicator light, gearbox oil filter 10
H9 Indicator light,4WD 69
H10 Indicator light, PTO 98
H11 Indicator light, parking brake 12
H12 Indicator light, Thermostart 6
H14 Indicator light, main beams 27
H15 Indicator, low fuel level 14
H16 Indicator light, charging 6
H18 Indicator light, gearb. oil temp. 13
H19 Indicator light, DPS I 102
H20 Indicator light, diff. lock 68
H21 Indicator light, DPS II 102
H22 Indicator light, DPS III 102
H23 Horn 50
(H24) Rotating roof beacon 47
(H27) Back buzzer 94
K 1 Relay, front working lights 43
K 2 Relay, rear working lights 41
K3 Relay,thermostart 6
K 4 Starter switch relay 8
K 5 Starter switch relay 9
K 6 Relay, fan III 56
K7 Brakelights 61
K9 Relay, intervalwiper 53
K10 Direction indicator relay 34
K14 Starter motor relay 4
K16 Relay, PTO---emergency stop 99
(K17) Relay, rear fog light 35
K18 Relay, Control stop 13
K19 Relay, display control, Sigma
M 1 Starter motor 3
M 2 Heating fan 55
M 3 Windscreen wiper 53
M 4 Windscreen washer 51
(M 5) Rear window wiper 49
(M 6) Rear window washer 48
(M 7) Floor fan 57
(M 8) Water pump 96
P 1 Engine coolant gauge 16
P2 Fuelgauge 17
P 3 Rev. counter 18
P 4 Hour meter/working height 19
Q 1 Starter switch 4
(Q2) Main switch 3
R1 Thermostart 5
R 4 Cigarette lighter 91
S 1 Switch, head lights 28
S2 Switch,rearworkinglights 41
S3 Switch, fan 55
S 4 Combination control 25,34,52
S 5 Switch, front working lights 43
(S6) Switch,rot.warninglight 47
