412
Model Code Page
35. Autocontrol IV
1. 4. 1997
6600E-- 8750E
350 28
S y m --- C o d e
bol Component no
S 7 Switch, hazard warning flashers 32
(S 8) Switch, air conditioner 54
S 9 Starter safety switch 4
S10 Brake light contact, right 62
S11 Fuel gauge sender unit 17
S12 Pressure drop indicator, air filter 7
S13 Engine oil press. sender unit 8
S15 Sender unit to hand brake ind. light 12
S16 Gearbox temperature sender unit 13
S17 Gearbox oil pressure sender unit 9
S18 Engine temp. sender unit (stop) 16
(S19) Air cond. compressor press. switch 54
S20 Brake light contact, left 62
S23 Switch, Delta Power Shift, selector 102
(S23) Extra sw., Delta Power Shift, selector 102
S24 Switch, Delta Power Shift release 100
S25 Switch, PTO 99
(S26) Switch, rear fog light 35
(S27) Switch, back buzzer 94
S28 Switch, PTO 540 99
S29 Switch, PTO 1000/ 540E 98
(S31) Switch, floor fan 57
(S32) Switch, rear window washer and wiper 48
(S33) Change over sw., head lights up 23
(S34) Switch, water pump 96
(S35) Rear steering prevention 93
S36 Switch, Control stop 4
(S38) Switch, Front PTO
S42 Door switch, right, cab light 46
S43 Door switch, left, cab light 46
(S44) Indicator light switch, gearbox filter 10
(S49) Change over switch, rpm ---/flow sensor
(S50) Change over switch, speed sensor
tractor / implement
V 1...4 Diodes (Y1, Y2, Y3, Y4, Y6)
V3 Diod, Control stop
X 1 Connector, 9---pole, distribution box
X 2 Connector, 9---pole, distribution box
X 3 Connector, 9---pole, distribution box
X 4 Connector, 9---pole, distribution box
X 5 Connector, 9---pole, distribution box
X 6 Connector, 9---pole, distribution box
X 7 Connector, 9---pole, distribution box
(X 8) Conn., 2---pole, power socket 92
X 9 Connector, 9---pole, combination control
X10 Connector, 9 ---pole, combination control
X11 Connector,9---pole,up
X12 Connector,9---pole,rearwards,right
X13 Connector, 9 ---pole, solenoid valves.
X14 Connector,9---pole,rearwards,left
(X15) Connector, 3---pole, air cond., diodes 54
(X16) Connector, 3--- pole, cigarette lighter,
current socket 91
X17 Trailer socket, 7---pole 32
(X18) Connector, 2---pole, rear window washer
X19 Connector, 32---pole, front wall
X20 Connector, 9---pole, front direction
indicator
(X22) Connector, 2 pole, rot. roof light
X23 Connector, 3---pole,Delta Power Shift,
extra switches
X24 Connector, 9 pole, upwards
X26 Connector, 26 pole, instr. left, white.
X27 Connector, 26 pole, instr. right, blue
( X 2 9 ) C o n n e c t o r, 2 --- p o l e , s t o p --- a l a r m
X 3 1 S o c k e t , 2 --- p o l e , P T O --- e m e r g . s t o p 9 9
X32 Connector,1pole,electricstop
(X33) Connector, 3---pole,fog light, rear
(X35) Connector, 9---pole, Sigma supply
(X36) Reserve
(X38) Reserve
(X39) Reserve
(X40) Reserve
(X49) Connector,2---pole,seat
Y 1 Solenoid valve, diff. lock 68
Y 2 Solenoid valve PTO 99
Y 3 Solenoid valve 4WD 69
Y 4 Solenoid valve, Delta Power Shift, 100
(Y 5) Solenoid valve compressor
(air.cond.) 54
Y 6 Solenoid valve, Delta Power Shift, 101
(Y7) Solenoid valve, rear
steering prevention 94
Y8 Solenoid, engine stop 4
(Y9) Solenoid, front PTO
(Y13) Solenoid valve, Sigma 113
(Y16) Solenoid, Cold cranking 3
GR1 Earth lead, rear lights, solenoids
GR2 Earth lead, roof
GR4 Earth lead, autocontrol
GR5 Earth lead, cable harness, instr. panel
GR7 Earth lead, battery
GR8 Earth lead, headlights
GR9 Earth lead, cabin
GR10 Earth lead, electrical stop
ACD POWER LIFT:
A1E Autocontrol 82
A2E Autocontrol, switch panel 83
A3E Compensator 82
B1E Position sensor 81
B2E Draft sensor, R.H 81
B3E Draft sensor, L.H 81
(B4E) Position sensor, implement 81
E1E Lighting, switch panel 83
E2E Lighting, position potentiometer 83
R1E Potentiometer, pos .control 83
S1E Switch, rear operation, r.h., lifting 82
S2E Switch, rear operation, r.h., lowering 82
S3E Switch, rear operation, l.h., lifting 82
S4E Switch, rear drive, l.h., lowering 82
S5E Switch, inside, lifting / lowering 82
S7E Switch, lowering speed 83
S8E Switch, top limit 83
S9E Switch, sensitivity /mixing 83
S10E Switch, lifting /lowering 83
S11E Switch, forced lowering 83
S12E Switch, drive balance system / slip 83
X1E Connector housing, 9 pole, speed sensors
X2E Connector housing, 9 pole,
EH --- supply, rear push buttons
Y1E Solenoid valve, lowering 82
Y2E Solenoid valve, lifting 82
(OPTIONAL EQUIPMENT IN PARENTHESES)
