544
Model
Code Page
15.04.1994 26000---8400 39
PTO EMERGENCY STOP, FITTING INSTR.
(3)
The power take off switch has 3 positions:
The front side pressed down = off position.
Theswitchinthemiddle = on position.
Rear side pressed down, spring return is the start-
ing position.
By pressing the rear side down the PTO is en-
gaged. By pressing the front side of the switch
down the PTO is disengaged.
The PTO is only disengaged temporarily with this
switch. The indicator light on the instrument panel
is still illuminated showing that the lever is en-
gaged. Always disengage the PTO by mo ving
thePTOlever tothemiddlepositione.g.when
leaving the tractor cab by moving the lever to
the middle position.
--- The PTO can be temporarily disengaged by push-
ing the PTO lever outwards (not when using
ground speed PTO).The PTO should be started
with switch.
--- The emergency stop outside the tractor can be
connected to operate in two different ways:
Method 1. Connect a rope from the operating posi-
tion on the implement to the stop plug.
Method 2. Connect a longer loop of cable to the
plug and have an emergency switch fitted in the
loop close to the operator.
--- After an emergency stop or stopping the tractor
engine the PTO will only start by pressing the
switch in the starting position
.
1 32916400 PTO---hätäpysäytys Nödstopp, PTO Emerg. stop,PTO Notstop, Zapfwelle
1 1 HD8005 .Ruuvi Skruv Screw Schraube M05X12
2 1 JB8902 .Mutteri Mutter Nut Mutter N M5
3 1 30943900 .Keinukytkin Vippströmbrytare Rocker switch Schalter 3--- Pos.
1 32887200 .Symbolilinssi Symbollins Lens Linse PTO
1 30944600 .Lampunpidin Lampfattning Bulb socket Lampenfuß
4 1 30944400 .Asennuspaneeli Panel Panel Panel
5 2 30944500 .Peitelevy Täckplatta Covering plate Deckplatte
6 1 32207200 .Pistorasia Stickdosa Plug socket Steckdose
7 1 32891500 .Levy Platta Plate Platte
8 1 32893700 .Tarra Dekal Sticker Aufkleber
9 1 32893900 .Oikosulkupistoke Stickkontakt Contact plug Steckkontakt
1 32893800 ..Haka Hake Hook Haken
10 1 32906800 .Vaihtorele Relä Relay Relais With diode
11 1 32908100 .Tulppa Täckplatta Covering plate Deckplatte
12 1 32916300 .Johdinsarja Ledningsats Wiring set Verkabelung
