547
Model
Code Page
114.06.2001 (6)
Electric stop / control stop, fitting instruction
8950Hi
39.11
6000---
11.01.1996
Electric stop + control stop (A+B) 33036300.
A) Electric stop of engine 32914200..........
B) Control stop 33005600...................
33005610
DNote! Tractors with starter switch 816450 (not
current supply to the other devices during start-
ing): the electric stop requires a new starter switch
(32553200, as standard from March ---94),
SHOULD BE ORDERED SEPARATELY
The starter switches can be recognized in switch
connectors.
D Note! 3-- and 4- -cyl. motors with in-- line inje-
ction pump: some models with air conditioner
must have an extra belt pulley (32889100)forair
conditioning compressor belt. SHOULD BE
ORDERED SEPARA TELY. (see picture A5)
--- The fuel injection pump is moved into the starting
position when the starter switch is switched to
position 1. The engine stops when the starter
switch is turned to position 0.
A) F I T T I NG ( p a g es 1 --- 3 ) :
--- Remove the engine hood side plates. Disconnect
the battery earth cable.
--- Remove the earlier stop control cable and fit the
cover plate, picture A1.
Change the cable lead---in rubber on the cab front
wall into the plug 14 (picture A2).
Up to ser. no 662342: T h e le a d --- in r u b b e r i s n o t
necessary to change (an extra wire is drawn
through the rubber hole).
--- Tractors with starter switch 816450:
Remove an earlier starter switch. Connect the cab
wiring loom to the new starter switch (32553200)
according to picture A3.
Tractors up to ser. no. 662342 (not AC II): Make a
wire (cross section 2,5 mm
2
, length 4 m, fit suitable
connectors to the wire ends). Connect the one end
of the wire to the starter switch pole 2 and pass the
other end through the lead---in rubber hole into the
engine compartment (see picture A4)
--- Tractors with starter switch 32553200 (current
supply also during glowing and starting):
It is unnecessary to change the starter switch.
--- Tractors equipped with air conditioner (3-- and
4--cyl.):
Fasten the extra belt pulley together with parts
95--- 105,seepictureA5.
