709
Model Code Page
42. Gearbox
15. 5. 1996
6000--8750 423 5
1. 1. 1995
2439
--- loosen the rail locking nuts
2
0
--- engage gear 1. Tap out the locking pins for the forks for
ge a r s 1 --- 2, 3 --- 4 a n d M --- H .
2
1
--- unscrew the rails from their adjusting pieces at the rear
ends and pull out the rails forwards.
2. Remove the circlip on the rail for gears AVO/LL (ground
speed PTO/LL---range). Open the nut at the front end of the
rail and remove the rail by turning it.
Note! Take care of the released balls and springs.
2442
3. Remove the forks for gears 1---2 and 3---4 on the input shaft
and remove also the sliding pieces.
4. Remove the forks for gears M---H, AVO and LL on the bevel
pinion shaft. Remove also the slidingpieces on the M---H fork.
Also the latest AVO and LL forks have sliding pieces.
