832
Model Code Page
46. Power take ---off
15. 5. 1993
6000--8750 462 2
8. 11. 1990
B. Removing PTO clutch
1. Remove the PTO unit (see instr. 1 A).
2. Remove the external lubricating oil pipes and the oil dis-
tributor piece.
Important! With effect from tractor searial no. 659787 the oil
pipes have been drawn in the different way, see picture10 on
page 460/13.
2484
3. Set the PTO selector lever to the neutral position (middle
position). Slacken the ground speed PTO shaft nut for easier
removing of the front cover.
Note! On the latesttractors it isunnecessary toslacken the nut
before removing the front cover.
Note! Prevent the ground speed PTO shaft from rotating e.g.
with pipe tongs. Open the nut with a standard spanner
wrench.
2490
4. Unscrew the front cover bolts. Pry out the cover with a fitting
lever and prevent the selec tor fork locking ball and spring
from springing from their place.
Note! Easiest way to remove the cover is to pry at the PTO
shaft front end. There is a guide sleeve on two fixing bolts on
upper and lower corner of the cover.
2485
5. Remove the PTO clutch and shaft from t he housing.
