853
Model Code Page
46. Front PTO
1. 4. 1997
6000--8150 463 11
D. Removing the front PTO/changing
v---belts/changing elastic joint,
6000---8150
Removing the front PTO unit:
1. Before removing the front PTO unit, the engine coolant
should be drained and the engine radiator and its cowl
mustberemoved.Atthesametimemustbereleasedthe
oil cooler and the air conditioner condenser and the drier
reservoir, if fitted (do not disconnect the hoses) .
2. Unscrew the bolts of the drive shaft flange joint in front
of the elastic joint (bolts A in the picture below). Unscrew
the PTO unit four fixing bolts, after which the unit can be
removed.
Note! If necessary, remove the front lift top link bracket. It is
possible to remove the front housing half while the rest of
the unit is attached to the tractor.
Changing v-- belts:
A
B
If the engine V---belts have to be changed on 6000---8150
tract ors, which ar e equipped with the front PTO, unscrew
the flange joint (A) in front of the elastic joint and then
remove the intermediate ring (B) , after which there is
enough space to remove/fit the belts.
Note! On 6000---6800 tractors (4---cyl.) the front PTO unit
must be inclined a little, if the trac tors have three belt
pulleys.
Changing elastic joint:
Before work the front PTO unit must be removed.
When fitting the elastic joint (140 Nm, 3+3 pcs (4---cyl),
4+4 pcs (6---cyl.)) apply a little grease onto the lower sur-
faces of the bolt heads (see also picture 16 o n page 463/4).
