SMDR Attributes (PGM 177) 1-87
Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
SMDR Attributes (PGM 177)
ITEM RANGE DEFAULT REMARK
SMDR Save Enable ON/OFF OFF The system can be set to record either all outgoing calls
(ALL) or only limit set by timer in Btn12 (SMDR Start
Timer).
SMDR Print Enable ON/OFF OFF The system can be set to real time print either all outgoing
calls (ALL) or only limit set by timer in Btn12 (SMDR Start
Timer)
SMDR Record Call Type LD/All Call LD The system can be set to record either all outgoing calls
or only long distance calls, exceeding the time limit set by
SMDR Start Tmr. The long distance calls are identified by
SMDR long distance code programming (Btn 15).
Records in Detail ON/OFF ON Due to limited system memory size, in places where many
calls take place, the SMDR record buffer can easily
become saturated. So, if the customer doesn't need the
detailed call information but total call, total metering count
and total cost for individual station, then it is possible to
save only the total accumulation, rather than the detailed
records in their entirety.
Print Incoming Call ON/OFF OFF If this option (PIC) is set to ENABLE, all incoming calls are
printed with either all outgoing calls or long distance calls.
Print Lost Call ON/OFF OFF If this option (PLC) is set to ENABLE, all lost calls are
printed whether unanswered or not.
SMDR Dial Digit Hidden 0-9 0 According to this value, the '*' symbol will be hidden in the
SMDR digits.
SMDR Currency Unit 3 Char -- For easy identification of call cost, the currency unit can
be input with 3 alphabetic characters to be printed in front
of the call charge amount.
SMDR Cost Per Unit
Pulse
6 digits -- This is the call cost unit per cost metering pulse, which is
sent from the Central Office.
SMDR Fraction 0-5 0 This value represents the decimal position point of the CO
per unit pulse.
SMDR Start Timer 000-250 000 1 sec base
SMDR Hidden Digit Right/
Left
Right Hide digits from right or left
