Toll Exception (PGM 224) 1-119
Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
Toll Exception (PGM 224)
Toll tables are used to have access to certain toll free calls as well as being denied certain calls
for the stations assigned STATION COS. Exception table A & B allow the station that is
programmed in STA COS 2, 3, & 4 to have access to certain toll free calls as well as being
denied certain calls.
The Allow/Deny Tables are organized into 2 sets of tables to support 2 different toll plans at one
installed site. Each allow/deny table may contain up to 30 number strings. All bins of allow and
deny tables have no entries by default. Each number string can contain up to 14 entries
including any number 0-9, *, #, "Don't care".
Use the following rules when setting up the Allow/Deny Tables:
• If the tables have no entries, no restriction is applied.
• If entries are made in the allow table and only there, then only those numbers are
allowed.
• If entries are made in the deny table and only there, then only those numbers are
denied.
• If there are entries in both tables, the allow table is searched first and if number is
found, it is allowed. If not found, the deny table is searched and if number is found, it is
denied. If it is not found in either table, it is allowed.
Allow/Deny Rules (PGM 224)
ENTRY CONDITIONS & RESULT
ALLOW DENY ALLOW TABLE DENY TABLE
Not Exist Not Exist No Restriction No Restriction
Exist Not Exist Found - allowed
Not found - denied
--
Not Exist Exist -- Found - denied
Not found - allowed
Exist Exist Found - allowed
Not found - check deny
table
Found - denied
Not found - allowed
