Toll Exception (PGM 224)
Toll tables are used to have access to certain toll-free calls as well as being denied certain
calls for the stations assigned STATION COS. Exception table A & B allow the station that
is programmed in STA COS 2, 3, & 4 to have access to certain toll free calls as well as
being denied certain calls.
The Allow/Deny Tables are organized into 2 sets of tables to support 2 different toll plans
at one installed site. Each allow/deny table may contain up to 30 number strings. All bins
of allow and deny tables have no entries by default. Each number string can contain up to
14 entries including any number 0-9, *, #, "Don't care".
The following rules should be remembered when setting up the Allow/Deny Tables:
• If the tables have no entries, no restriction is applied.
• If entries are made in the allow table and only there, then only those numbers are
allowed.
• If entries are made in the deny table and only there, then only those numbers are
denied.
• If there are entries in both tables, the allow table is searched at first and if number
is found, it is allowed. If not found, the deny table is searched and if number is
found, it is denied. If it is not found in either table, it is allowed.
Allow/Deny Rules (PGM 224)
ENTRY CONDITIONS & RESULT
ALLOW DENY ALLOW TABLE DENY TABLE
Not Exist Not Exist No Restriction No Restriction
Exist Not Exist Found - allowed
Not found - denied
--
Not Exist Exist -- Found - denied
Not found - allowed
Exist Exist Found - allowed
Not found - check deny
table
Found - denied
Not found - allowed
