Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
Tables
LCR Assignment ( PGM 220)
LCR is a function you can program to select the least-costly CO line automatically for day/night,
and any specified time zone. The LCR table has four parts. In PGM 220, you can program the
general database, LCR access mode, day zone, and time zone.
Operation
1. Click [LCR Assignment].
2. Select an LCR Access Mode.
M00: LCR is not used
M01: Only Loop LCR
M02: Internal and Loop LCR
M11: Loop and Direct CO LCR
M12: Internal, Loop and Direct CO LCR
A duplicated day cannot be assigned for different day zones. If you want to select
Saturday for Day Zone 2, select "Zone 2" in the SAT combo box.
For each day zone, you set time-of-day. The time also cannot be duplicated for each day
zone.
3. After programming, press the [Update] button to save the changes.
