Networking Programming 2-129
Chapter 2: SBX IP Offline PCAdminPro
SBX IP - PC Admin Guide
Netw orking Programming
You can program for networking SBX IP systems. The programming number range is from PGM
320 to PGM 324.
Netw orking Attributes ( PGM
320/ PGM321)
Networking Basic Attribute (PGM 320)
BTN ITEM RANGE DEFAULT REMARK
1 Network Enable ON/OFF OFF Enable Networking function
2 Network Retry Count 00-99 00 No need at direct connection between
SBX IP systems. This field is available at
connection through the public network.
3 Network CNIP Enable ON/OFF ON The name of the calling station is sent to
the called system between SBX IP
systems. CNIP is displayed at called
party stations display based on the
programming.
4 Network CONP Enable ON/OFF OFF Reserved
5 Network Signal Method FAC/UUS FAC Select the information element type for
QSIG supplementary service message.
