Print Serial Port Selection (PGM 175) 1-83
Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
Print Serial Port Selection ( PGM 175)
You can change the usage of the print serial port. You can change the various input port for
application.
Note:
The PC Admin port is only displayed and you can't change the value.
If the PC Admin port is COM1-COM2 for PC application (PC Admin, PC Attendant, CTI), you
can't use those ports (COM1-COM2) as normal terminal ports during use of PC Admin. Except
for PC Admin, you have to change the ports related with the PC application to DEFAULT VALUE
(Network) before you use those ports for normal usage (Trace, SMDR Printing…). If you do not
change those values, the system may experience problems.
ITEM RANGE DEFAULT REMARK
Baud Rate 0-7 19200 0: N/A 1: N/A
2: 1200 Baud 3: 2400 Baud
4: 4800 Baud 5: 9600 Baud
6: 19200 Baud 7: 38400 Baud
CTS/RTS ON/OFF OFF --
P-Break ON/OFF OFF --
LPP 001-199 060 --
