Vertical SBX IP - LCR Assignment (PGM 220)

LCR Assignment (PGM 220) 1-113
Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
LCR Table (PGM 220)
ITEM RANGE DEFAULT REMARK
LCR
Access
M00
M01
M02
M11
M12
M13
Disable
M00)
LCR Access Mode 00 (M00): Disable LCR
LCR Access Mode01 (M01): only Loop LCR.
LCR Access Mode02 (M02): Internal and Loop LCR.
LCR Access Mode11 (M11): Loop and Direct CO LCR
LCR Access Mode12 (M12): Internal, Loop, and Direct CO LCR.
LCR Access Mode13 (M13): Internal, Loop, Direct CO, and Direct Loop LCR.
Day Zone Zone: 3
Day: 1-7
Belongs to
Zone 1
First, select day and choose zone.
Time
Zone
Time:
00-24
Belongs to
Zone 1
The system accepts the same value for 00 and 24 and changes to "00", if 24
is input as the starting value and vice versa.
*Note: The time not belonging to any zone will be considered as zone 1.
*Note: 10-13 represents 10:00:00 - 12:59:59
