System Base Program 2-54
Chapter 2: SBX IP Offline PCAdminPro
SBX IP - PC Admin Guide
System Base Program
Use the System Base Program to change any system features.
System Attributes ( PGM 160/ 161/ 163)
This area of programming changes system attributes.
Operation
1. The System Attribute 1 window will display and you can select the Attribute II or
Attribute Alarm by clicking the appropriate tab. Then you can view the current setting
and update each field.
2. Refer to the following tables and change the values as desired.
3. After editing, press the [Update] button to save the changes.
Ring Detection Time (10) 2-9 2 The Ring DTC (detect) timer defines the minimum
acceptable length of the Ring-on time during a ring
cycle.
Ring Stop Time (100ms) 10-60 60 The Ring Stop timer defines the maximum Ring-off
time during a ring cycle.
Collect Digit 1-6 3 Collect DGT (digits) defines the number of digits
expected on a DID line.
Store Time (sec) 1-15 15 For DID lines, this timer defines the maximum
delay between incoming DID digits.
T1 CO Line Attribute (PGM152)
ITEM RANGE DEFAULT REMARK
