Local Code Table (PGM 204) 2-125
Chapter 2: SBX IP Offline PCAdminPro
SBX IP - PC Admin Guide
Local Code Table ( PGM 204)
You can assign the local codes in this table. The local code entered in this table will be deleted
in SMDR print. The telephone no. with this code will not be recognized as a long distant call.
The available code value is numbers and digits (0-9, *, #) and is limited to a maximum length
of 5.
I ncoming CLI Destination Table ( PGM 237)
An incoming DID destination can be associated with the incoming CLI. If a CLI number is
registered and assigned a destination within the Incoming CLI Destination Table, all DID calls
with this CLI will be routed to the corresponding destination.
Note: - This feature is supported only when the CO type is set as DID.
- This feature is executed first, when system receives a DID call with CLI.
Voice Mailbox COS (PGM 238)
The system provides administrative options to create COS for voice mailboxes. These COS can
then be programmed to stations/mailboxes on an individual basis. Up to 5 COS may be
programmed. NOTES: The default Class of Service for all mailboxes is 1.The parameters in
COS 1 contain all default settings.
(PGM 237)
BTN ITEM RANGE DEFAULT REMARK
1 CLI Number 001-100 --
2 Conversion Index Table -- --
(PGM 238)
BTN ITEM RANGE DEFAULT REMARK
1 Greeting Length 00-99 15
2 Message Record Time 001-600 secs 300
3 Number of Messages 01-250 50
4 Message Retention Time 01-99 days 15
5 E-mail Notification Enable/Disable Disable
6 Future Delivery Enable/Disable Disable
7 Confirm Message Receipt Enable/Disable Disable
8 Private Message Mark Enable/Disable Enable
