Networking Attributes (PGM 320/PGM321) 1-140
Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
Networking Basic Attribute (PGM 320)
BTN ITEM RANGE DEFAULT REMARK
1 Network Enable ON/OFF OFF Enable Networking function
2 Network Retry Count 00-99 00 No need at direct connection between
SBX IP systems. This field is available at
connection through the public network.
3 Network CNIP Enable ON/OFF ON The name of the calling station is sent to
the called system between SBX IP
systems. CNIP is displayed at called
party stations display based on the
programming.
4 Network CONP Enable ON/OFF OFF Reserved
5 Network Signal Method FAC/UUS FAC Select the information element type for
QSIG supplementary service message.
6 Net CAS Enable ON/OFF OFF Enable Centralized attendant
In master system, CAS should be
disabled.
7 Net VPN Enable ON/OFF OFF Enable the VPN function
8 Net CC Retain Mode ON/OFF OFF --
Networking Supplementary Attribute (PGM 321)
BTN ITEM RANGE DEFAULT REMARK
1 Networking Transfer Mode RERT/JOIN REROUT Only Transfer by Rerouting is possible
2 TCP Port 0000-9999 9000 TCP port for BLF message
3 UDP Port 0000-9999 9001 UDP port for BLF message
4 BLF Manager IP Address 12 digits 0.0.0.0 IP Address of BLF manager for BLF
service
5 Duration of BLF Status 01-20 sec 02 Duration of BLF status message
6 Multicast IP Address 12 digits 0.0.0.0 IP address of Multicast for BLF service
7 Net Trans Fault Recall Timer 001-300 010 Network transfer fault recall timer
8 VOIP Call Reroute CO Group 00-24 00 Used to set the CO group of
gatekeeper.
