Hardware/Software Requirements 1-2
Chapter 1: SBX IP Online PC Admin
SBX IP - PC Admin Guide
Cable
• RS-232C Type Cable to connect the PC and the SBX IP system: Two connectors are
needed for this connection. One connector must be a 9-pin female connector that is to
be connected to the SBX IP, and the other one must fit the serial port of the PC. There
are three required lines that must be connected for the communication between the
PC and the SBX IP system: Ground-Ground, Transmit-Transmit, and
Receive-Receive.
• RS-232C Type Cable for connecting PC and the system to be routed: There are three
required lines that must be connected between the PC and the system to be routed:
Ground-Ground, Transmit-Receive, and Receive-Transmit.
• UTP cable is used for the LAN connection.
Environments for LAN connection
• The SBX IP system should have one IP address and it has to be set for the MPB using
PGM108 - Flex button 2.
• If your site uses the firewall or NAT (Network Address Translation)/PAT (Port Address
Translation) for security, you need help from the network administrator to use the PC
Admin software for remote access.
• If you don't remember the above information, you will not be able to connect to the
SBX IP system from outside using PC Admin via Internet.
