Configuration (PGM 100-103) 2-16
Chapter 2: SBX IP Offline PCAdminPro
SBX IP - PC Admin Guide
Operation
• After changing the nation, you must save the database file and upload it to the SBX IP
system. Also, you have to reset the system without DB protection. At that time Dip S/W 4
must be set to the ON state.
• For another admin modification, you download the changed database file.
Slot Assignment (PGM 101)
The SBX IP system supports 10 slots. This program assigns each slot to one type of the boards.
After changing the Slot Assignment, you must save the database file and upload it to the SBX
IP system and then reset the system.
For another admin modification (Station, CO, etc), you download the changed database file.
Logical Slot Assignment (PGM103)
This area of programming sets up COL board, STA board, and VMIB.
Operation
If any board is preset automatically by the system, it shows the boards on the dialog box.
1. Add the slot to a location on the right side of the dialog box. If you select the Station
board, assign the slot to the station window.
2. To change the order of slots, use [Up] and [Down] button to change the order of the
boards.
3. After editing, press the [Update] button to save change values.
