- Height adjustment -
• Detach translatory lever 1 from
axle 2 (swivel plate).
1
2
• Remove retaining ring 1 using long-
nose pliers.
1
• Slightly raise detent segment 1 and
insert translatory lever 2.
• Detach translatory lever 1 from
axle 2 (swivel plate).
1
2
• Slightly raise detent segment 1 and
remove translatory lever 2.
07.03.02 Installing translatory
lever
 07.03.01 (A)
07.03.01 (A)
• Unscrew nut 1, detach translatory
lever 2 from axle 3 (swivel plate with
pin).
1
3
2
Models MB 650.0
from serial number 4 31 244 752
Models MB 655.0
from serial number 4 31 230 688
Models MB 655.1
 07.03.01 (A)
