Chapter 2 General Information ALPHA V40
Version 18.07.06
14
2. General Information
This section describes general functional and logistical information regarding
the machine and its usage. This includes air and power source
specifications, illustrations that identify the primary working components on
the machine, and illustrations that identify the various machine layouts and views.
Compressed Air and Power
The Label Applicator requires electrical power and compressed air (for Blow-Box or Tamp
applicators). The compressed air must be clean and dry. Typical air pressure is 85 PSIG (6.0
bar). The air pressure must always be greater than the highest pressure setting on the
machine. 3 SCFM is the typical air volume requirement. The rate of production and the label
size can effect the air supply requirements. If you have problems in this area, check with Weber
Customer Support.
Specifications
Label-Format (for Wipe-On applications)
min. 20 x 12 (width x length in mm)
max. 120 x 500 (width x length in mm)
optionally width 7 mm min., length 2500 mm max.
Label-Roll
Outside diameter Ø = 300 mm (equals 450 meters)
Core: 76 mm (3 “) and outside winding preferred
Speed and Rate of Label Application Wipe-On / Blow : up to 600 Labels per Minute.
Tamp-Applicators: up to 120 Labels per Minute
Distance for Label Application
0 – 20 mm is the distance from the tamp plate to the
product. Depending on label sizes and quality and
accuracy of placement.
Accuracy of Placement +/- 1 mm, for Wipe-On and Tamp-On Applicator
Label Carrier (Rewind) Up to 170 mm diameter (equals 450 m)
LCD backlit Display Display : backlit LCD, 2-lines with each 16 characters,
Panel Key [ENTER]- , [] and [] -keys,
Dimensions: Controller
Applicator
187 x 255 x 75 mm (L x W x H)
700 x 300 x 500 mm (L x W x H) depending on
applicator version).
Weight (with out label-roll) approx. 22 kg depending on applicator version
Operating voltage 115 VAC (60 Hz) , 2A
230 VAC (50 Hz), 1A
Fuse T 2A / 250V (for 230 V)
T 4A / 250V (for 115 V)
Air Pressure (only for Blow-Box and Tamp
applicators)
6 bar, according to DIN ISO 8573-1
- content of residual oil 25 mg/m³ (Quality-Guard 5)
- residual dust 5µm ; 5 mg/m³ (Quality-Guard 3)
- residual water 6 g/m³ ; +3 °C (Quality-Guard 4)
Air Consumption 200 Nl/min, with maximum rate of application.
0,3 - 3 Litre per cycle of application
Environmental Operating Range
10°-38° C Temperature,
10-95 % relative humidity (non-condensing).
.
