Chapter 6 Display-Controller ALPHA V40
Version 18.07.06
80
Address 06 (Page 0), encoder reading
Here is made the entering of the impulse length of the connected shaft encoder. To enable the
variable labelling choose "0.4" at Address 08 (optional at "LINE SPEED" in Programming
Mode). Now the speed is automatically regulated in the range 0.5 to 22 m/min. As of a higher
speed the machine stops in error condition.
The controller implies in its default setting 1470 impulses for a conveyer speed of 10 m/min (this
corresponds 100 impulses read during a Timeframe of 68ms). It matches for example to an
encoder of 1754 impulse/turns supported by a friction wheel of 200 mm circumference.
0 06 = Value
for currently Timeframe for receiving 100 impulses (default 68)
If it should be required to change that value please calculate the result with the
following formula:
00 - 255
=
24
= recommended standard value of an optional 5000s shaft encoder supplied fro
Geset supported by a friction wheel of 200 mm circumference (Ø = 63,6 mm)
*68
= The default value matches to 1754 i/turns encoder supported by a friction wheel
of 200 mm circumference (Please refer to page 33).
SERVICE PROGRAM
0 06= 68
Input =
(Timeframe)
Circumference of Friction Wheel [mm] x 600
Encoder [i/turns]
