Chapter 6 Display-Controller ALPHA V40
Version 18.07.06
66
Programming Mode
The ALPHA V40 contains up to 30 different label formats (how to change, see page 64). You
are able to call up every parameter of a stored label format. In the Programming Mode the
current label format is displayed on the rightmost position of the first line. Every change of a
label parameter refers to the current label format. The Programming Mode is used to set up the
ALPHA V40 to a certain label material. See the utilities of the menu as follows:
- LINE SPEED
- LABEL POS.
- REFER. EDGE
- GAP LEVEL
- LABEL LEVEL
- TRIG. DELAY
- SYNC PULSE
- TRIG. BLANK
- LABEL QUEUE
- CALIBRATE SENSOR
- CALIBRATE LABEL
- STORE PARAMETERS
With “Store Parameters” you overwrite the existing parameters of the current label format.
Accordingly, select an unused label format before you start to setup the ALPHA V40.
NOTE: An overwritten label format can not be cancelled or recalled.
LINE SPEED
This is the nominal speed (in m/min) at which the label is dispensed. For Wipe On systems, it
should match the speed of the product on the conveyor line, special in case of low speeds
and/or long labels. Please note that the operation with shaft encoder can be enabled by setting
the parameter at "0.4", refer to the page 80.
Press []- and [Enter]-keys simultaneous, until the following screen displays:
Label Format
PROGRAMMING 01
LINE SPEED 12.3
Parameter
Press either [] or [] key to move to the next setting.
Use the [Enter]-key to edit the parameter. The [] and []-keys increase or decrease the
value. In the range of 0.5 to 21.1 m/min the Line Speed has a compartment of 0.1 m/min.
While from 22.1 to 64.1 each step is 1 m/min. Press the [Enter]-key again to confirm your
setting.
This parameter can also be adjusted in real-time, during normal operation, through the [] and
[] keys, (depending on the parameter setting of Address 07, see Page 81 ). But the changed
