Chapter 6 Display-Controller ALPHA V40
Version 18.07.06
88
Set up V40 to Tamp-Blow Applikator
Address 0 02
bit 0 1 2 3 4 5 6 7 Byte 0 02
value 1 2 4 8 16 32 64 128 Input value System - Blow - Box
X X
3
P-sensor starts the label feed.
S-sensor starts the tamp extension and air blast of the
label
X
*4
The label is feed automatically subsequent tamp
extended. To blow on the label is only triggered via S-
sensor (P - sensor without function)
X X
5
P-sensor starts feeding the label under the tamp pad. The
tamp extends and waits.
S-sensor starts the air blast.
The values of bytes/addresses…..
Address 0 248 (time out for home detection) = the maximum duration for tamp retraction.
Time starts at the beginning of retract motion until tamp is in home
position. Home position is displayed as a “H“.
The proximity sensor (for variable stroke) appears as X when it is active. A fix mounted
extended tamp sensor, is not useful, either a variable stroke sensor is used or the air blast dwell
is set via Byte 0 249 (tamp to blow delay).
Address 0 249 Duration from tamp extension until start of tamp retraction. Its value has set to
“01”, independent of using the proximity sensor. If value is “00”, no tamp
moving.
Address 0 250 Time-Out for proximity sensor. During this time the proximity sensor must be
activated. If not following message appears “MISSING PRODUCT”.
