Chapter 6 Display-Controller ALPHA V40
Version 18.07.06
82
The next block of eight addresses belongs to the label format 01.
 NOTE: For each label format (30) exists a block with same addresses and parameters. In
the matter of fact this is renounced to repeat all addresses for each label. So that address
08 represents the address 16 (of label format 02), also 24 (of label format 03)… Of course
same according to address 09 (of #1) represents the address 17 (of #2), …
 These blocks of 8 addresses are matching to the parameters of Programming Mode
(refer to page 66)
Address 08 (Page 0), dispensing speed (of label format #1)
0 08 = Value for currently selected dispensing speed
00 – 255
= LINE SPEED
Address 09 (Page 0), label positioning (of label format #1)
0 09 = Value for currently selected label position
00 – 255
= LABEL POS.
Address 10 (Page 0), gap level (of label format #1)
0 10 = Value for currently selected gap level
00 – 255
= GAP LEVEL
Address 11 (Page 0), label level (of label format #1)
0 11 = Value for currently selected label level
00 – 255
= LABEL LEVEL
