Chapter 3 Preliminary Setup ALPHA V40
Version 18.07.06
20
3. Place the applicator with its backside on an adequately stable work surface that is
approximately high of your stand.
4. After proper assembly of the stand (per assembly instructions), adjust the height of the
carriage if available until the machine.
5. Assemble the applicator to the stand and tighten the lock washer and nut securely.
6. Also the controller unit can be mounted onto a metal tube (diameter Ø = 30 mm) using a
flange.
7. The screw holes are located at the lower side of the controller. Please screw the flange onto
this area and tuck the unit onto the stainless steel tube.
