NOTE
• Lighting patterns when the lamp is lighted by ECU directly.
9Y1210828ENM0040US0
Permit
: Lighting, : Blinking
9Y1210828ENM0041US0
Inhibit
: Lighting, : Blinking
9Y1210828ENM0042US0
Auto Regeneration
Permit
RGN and
Inhibit
Lamp
Manual
RGN
Demand
Lamp
Warning
Lamp
State of Regeneration
Level 0
(No need Regeneration)
Regeneration is not required
Level 1
(Auto Regeneration)

Regeneration starts automatically when the PM level reachs to
this level.
Parked regeneration is impossible in this level.
Level 2
(Request parked
Regeneration)

ECU requests parked regeneration if the PM level does not
decrease to automatic regeneration level in 1800 seconds after
automatic regeneration starts.
(Automatic regeneration does not stop in this level.)
Level 3
(Parked Regeneration)

Automatic regeneration stops.
Operator had better park the machine and start manual
regeneration as soon as possible.
During parked regeneration, machine operation is restricted.
Level 4
(Regeneration with
service tools)

Parked regeneration is impossible.
Regeneration is possible with service tools only.
(Service tools are available among all levels without level 5)
Level 5
(DPF Cleaning)

Regeneration is impossible even with service tools.
DPF cleaning is necessary.
Auto Regeneration
Inhibit
RGN and
Inhibit
Lamp
Manual
RGN
Demand
Lamp
Warning
Lamp
State of Regeneration
Level 0
(No need Regeneration)
 Regeneration is not required
Level 1
(Auto Regeneration)
 Automatic regeneration inhibit
Level 2
(Request parked
Regeneration)

ECU requests parked regeneration if the PM level does not
decrease to automatic regeneration level in 1800 seconds after
automatic regeneration starts.
(Automatic regeneration does not stop in this level.)
Level 3
(Parked Regeneration)

Automatic regeneration stops.
Operator had better park the machine and start manual
regeneration as soon as possible.
During parked regeneration, machine operation is restricted.
Level 4
(Regeneration with
service tools)

Parked regeneration is impossible.
Regeneration is possible with service tools only.
(Service tools are available among all levels without level 5)
Level 5
(DPF Cleaning)

Regeneration is impossible even with service tools.
DPF cleaning is necessary.
