TRANSMISSION
M6060, M7060, WSM
2-S1
1. TROUBLESHOOTING
Symptom Probable Cause Solution
Reference
Page
Shuttle Clutch Slip Operating pressure is low Adjust 2-S15
Shuttle clutch valve malfunctioning Replace 2-S24
Clutch disk or steel plate excessively worn Replace 2-S59
Deformation of piston or steel plate Replace 2-S59
Shuttle Clutch
Operating Pressure Is
Low
Transmission oil improper or insufficient Fill or change G-36
Relief valve malfunctioning Adjust or replace 2-S15
Shuttle Clutch Drags Return spring weak or broken Replace –
Modulating valve malfunctioning Replace 2-S24
Deformation of piston or steel plate Replace –
Tractor Does Not
Keep in Neutral
Shuttle linkage defective or deformed Adjust or replace 2-S7
PTO Clutch Slip Operating pressure is low Adjust 2-S17
PTO solenoid valve malfunctioning Replace 2-S24
Clutch disk or drive plate excessively worn Replace 2-S61
Deformation of piston or return plate Replace 2-S61
PTO Clutch
Operating Pressure Is
Low
Transmission oil improper or insufficient Fill or change G-36
Relief valve malfunctioning Adjust or replace 2-S15
PTO Clutch Drags Return spring weak or broken Replace 2-S61
Modulating valve malfunctioning Replace 2-S24
Deformation of piston or steel plate Replace 2-S61
PTO Does Not Rotate PTO clutch malfunctioning Replace 2-S61
4WD Clutch Slip Operating pressure is low Adjust 2-S16
4WD solenoid valve malfunctioning Repair or replace 2-S24
Clutch disk or drive plate excessively worn Replace 2-S60
Deformation of piston, steel plate or pressure
plate
Replace 2-S60
Front Wheel Does
Not Rotate
4WD clutch malfunctioning Repair or replace 2-S46
4WD propeller shaft coupling disengaged Engage –
4WD Operating
Pressure Is Low
Transmission oil improper or insufficient Fill or change G-36
Relief valve malfunctioning Adjust or replace 2-S15
Differential Lock
Pedal Does Not
Return
Differential lock cam spring weaken or damaged Replace 2-S50
Differential shift fork pin damaged Repair or replace 2-S50
Differential lock holder pin damaged Repair or replace 2-S50
Differential Lock Can
Not Be Set
Differential lock shift fork damage Replace 2-S50
Differential lock shift fork mounting spring pin
damaged
Replace 2-S50
Movement of differential lock shifter improperly
adjusted
Adjust 2-S68
