ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S24
(3) Adjusting Throttle Sensor
Memorize Throttle Sensor Value
NOTE
• Before inputting the throttle sensor value in the tractor
ECU, warm up the engine about 10 to 15 minutes.
9Y1210828ELS0040US0
Adjusting the Throttle Sensor
1. Select the "ADJ-1" mode.
2. Start the engine.
3. Travel speed select switch press and hold longer than 2
seconds.
4. "SET 0" is displayed.
5. Set the hand accelerator lever (1) and pedal at idling position
(Min.).
6. Press the travel speed select switch press and hold those
longer than 2 seconds.
7. "WAIT" is displayed.
9Y1210828ELS0041US0
(1) PTO/Hour Meter Select Switch (2) Traveling Speed Select Switch
(1) Hand Accelerator Lever
