GENERAL
M6060, M7060, WSM
G-34
[6] CHECK POINT OF EVERY 400 HOURS
Cleaning Water Separator
This job should not be done in the field, but in a clean place.
1. Close the fuel valve (1).
2. Remove the cup (2) and remove it, then rinse the inside with
kerosene.
3. Remove the element (4) and dip it in the kerosene to rinse.
4. After cleaning, reassemble the water separator, keeping out
dust and dirt.
5. Bleed the fuel system. (See page G-44.)
• If the water separator and/or fuel filter is not well
maintained, the supply pump and injector may be damaged
earlier than expected.
9Y1210828GEG0034US0
[7] CHECK POINTS OF EVERY 500 HOURS
Changing Engine Oil
• See page G-22.
9Y1210828GEG0035US0
Changing Engine Oil Filter
• See page G-22.
9Y1210828GEG0036US0
Replacing Hydraulic Oil FIlter
• Allow engine to cool down sufficiently, oil can be hot and
can burn.
1. Remove the drain plug (1) at the bottom of the transmission
case and drain the oil completely into the oil pan.
2. After draining reinstall the drain plug (1).
3. Remove the two oil filters (2).
4. Wipe off metal fillings with clean rags at the magnetic filters.
5. Put a film of clean transmission fluid on rubber seal of new
filters.
6. Tighten the filter quickly until it contacts the mounting surface.
Tighten filter by hand and additional 1/2 turn only.
7. After the new filter has been replaced, fill with the oil up to the
upper notch on the dipstick (3).
8. After running the engine for a few minutes, stop it and check the
oil level again, add oil to the prescribed level.
9. Make sure that the transmission fluid doesn't leak through the
seal.
• To prevent serious damage to the hydraulic system, use
only a KUBOTA genuine filter.
9Y1210828GEG0037US0
(1) Fuel Valve
(2) Cup
(3) O-ring
(4) Element
(5) Element Cup
(6) Red Float
(7) Drain Plug
(A) Close
(1) Drain Plug
(2) Hydraulic Oil Filter
(3) Dipstick
(4) Oil Filling Plug
(A) Oil level is acceptable within this
range.
To Next Page
