wsm M7060 - 2 Servicing Specifications

CABIN
M6060, M7060, WSM
9-S5
2. SERVICING SPECIFICATIONS
9Y1210828CAS0002US0
Item Factory Specification Allowable Limit
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
Pressure
(HI Pressure Side)
0.15 to 0.19 MPa
1.5 to 2.0 kgf/cm
2
22 to 28 psi
1.3 to 1.6 MPa
13 to 17 kgf/cm
2
190 to 240 psi
–
–
Magnetic Clutch Stator Coil Resistance 3.0 to 4.0 Ω –
A/C Compressor Magnetic Clutch Air Gap 0.30 to 0.65 mm
0.012 to 0.025 in.
–
Blower Resistance
(Terminal Hi -
Ter m in al M2)
(Terminal Hi -
Ter m in al M1)
(Terminal Hi -
Ter m in al Lo)
Approx. 0.22 Ω
Approx.0.69 Ω
Approx.1.69 Ω
–
–
–
Pressure Switch
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Setting Pressure
(HI Pressure Side)
Less than
approx.
0.20 MPa
2.0 kgf/cm
2
28 psi
More than
approx.
3.1 MPa
32 kgf/cm
2
460 psi
–
–
Front Wiper Rotating Speed 25 to 43 times/min. –
Rear Wiper Rotating Speed 25 to 43 times/min. –
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.40 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Air-gap of A/C Compressor Magnetic Clutch Air-gap 0.30 to 0.65 mm
0.012 to 0.025 in.
–
KiSC issued 08, 2013 A
