wsm M7060 - Servicing Specifications

STEERING
M6060, M7060, WSM
6-S2
2. SERVICING SPECIFICATIONS
9Y1210828STS0002US0
Item Factory Specification Allowable Limit
Relief Valve Setting Pressure At Idling Engine
Speed
At Maximum
Engine Speed
Above
12.3 MPa
125 kgf/cm
2
1780 psi
Below
18.6 MPa
190 kgf/cm
2
2700 psi
–
–
Toe-in 2.0 to 8.0 mm
0.079 to 0.31 in.
–
Steering Cylinder I.D. 55.000 to 55.074 mm
2.16535 to 2.16827 in.
55.100 mm
2.16929 in.
Rod to Bushing Clearance 0.010 to 0.140 mm
0.00039 to 0.00551 in.
0.250 mm
0.00984 in.
KiSC issued 08, 2013 A
