TRANSMISSION
M6060, M7060, WSM
2-S2
9Y1210828TRS0120US0
Excessive
Transmission Noise
Transmission fluid insufficient Fill G-36
Improper backlash between bevel pinion shaft
and bevel gear
Adjust 2-S63,
2-S65
Improper backlash between differential pinion
and side gear
Adjust 2-S68
Collars or shims have not been installed Repair –
Bearing worn Replace 2-S57
Gears Slip Out of
Mesh
Shifter or shift fork worn or damaged Replace 2-S38,
2-S57
Shift fork spring weaken or damaged Replace –
Interlock ball fallen Reassemble –
Synchronizer unit damaged Repair or replace 2-S41
Hard Shifting Shifter or shift fork worn or damaged Replace 2-S57
Shift fork rod bent Replace –
Synchronizer unit damaged Repair or replace 2-S41
Gears Clash When
Shifting
Synchronizer unit damaged Repair or replace 2-S41
Symptom Probable Cause Solution
Reference
Page
KiSC issued 08, 2013 A
