wsm M7060 - Page 16

INFORMATION
M6060, M7060, WSM
I-12
CABIN Model
The company reserves the right to change the specifications without notice.
NOTE
• *1: Manufacture's estimate
*2: At lower link end with links horizontal.
*3: At lower link end with links horizontal.
*4: According to EN 15695-1: 2009
Model
M6060 M7060 M7060-SPA
4WD
Engine
Model V3307-CR-TE4
Type 4-cylinder in-line, Common Rail System, direct injection
Number of cylinders 4
Total displacement 3331 cm
3
(203 cu.in.)
Bore and stroke 94 × 120 mm (3.7 × 4.7 in.)
Rated speed 2400 min
-1
(rpm)
Net power*
1
47.3 kW (64.3 PS) 52.9 kW (71.9 PS)
Gross power*
1
49.5 kW (67.3 PS) 55.4 kW (75.3 PS)
Maximum torque
229 N·m (23.4 kgf·m,
169 lbf·ft) /
1400 min
-1
(rpm)
258 N·m (26.3 kgf·m, 190 lbf·ft) / 1400 min
-1
(rpm)
Battery capacity 12 V, RC: 160 min, CCA: 900 A
Fuel tank capacity 90 L (24 U.S.gals, 20 Imp.gals)
Engine oil capacity 12 L (12.7 U.S.qts, 11 Imp.qts)
Coolant capacity 8 L (8.5 U.S.qts, 7 Imp.qts)
Dimensions
Overall length 3675 mm (144.7 in.)
Overall width (minimum tread) 1855 mm (73.03 in.) 1965 mm (77.36 in.)
Overall height 2580 mm (101.6 in.) 2520 mm (99.21 in.)
Wheel base 2110 mm (83.07 in.)
Tread
Front 1450 to 1540 mm (57.09 to 60.63 in.)
1365 to 1415 mm
(53.74 to 55.71 in.)
Rear 1415 to 1735 mm (55.71 to 68.31 in.)
1545 to 1740 mm
(60.83 to 68.30 in.)
Minimum ground clearance 390 mm (15.4 in.) 330 mm (13.0 in.)
Weight 2725 kg (6008 lbs) 2655 kg (5853 lbs)
Traveling
system
Standard tire
size
Front tire 320/85R20 320/70R20
Rear tire
*2
420/85R30 (16.9-30) 420/70R28
Clutch Hydraulic multiple wet disks
Steering Hydraulic power steering
Braking system Hydraulically operated wet disks
Trailer brake Hydraulic
Trailer brake couple ISO 5676
Differential Bevel gears with differential lock (Rear)
Hydraulic
system
Hydraulic control system Position, draft (top link sensing) and mix control
Pump capacity 61.5 L (16.2 U.S.gals, 13.5 Imp.gals) /min
3-point hitch SAE Category 1 and 2
Max. lifting
force
At lifting
points*
3
2300 kg (5071 lbs)
Remote hydraulic control 2 standard (3rd and flow control valve optional)
Remote control valve coupler ISO 7241-1 standards "A"
System pressure 19.1 MPa (195 kgf/cm
2
, 2770 psi)
Traction system Swinging drawbar, adjustable in direction
PTO
Live PTO
(Independent)
Direction of
turning
Clockwise, viewed from tractor rear
PTO speed
6 spline: 540 min
-1
(rpm) / 2160 min
-1
(rpm) engine speed
6 spline: 540E min
-1
(rpm) / 1828 min
-1
(rpm) engine speed
The level of protection against hazardous
substance
*4
Category 1
KiSC issued 08, 2013 A
